Bose F1 812 Service Manual

48
ELECTRICAL PART LIST
F1 Model 812 Input-Output / DSP PCB Assembly
Transistors (continued)
Reference
Designator
Description
V
endor Part
Number
Note
Q11 XISTR, PNP, KST92, , SOT-23,TRANSISTOR RCP000092-0001
Q12 XISTR, NPN, MMBT3904, SOT-23, LRC, GENERAL
PURPOSE AMPLIFIER
RCN003904-0008
Q13 XISTR, NPN, MMBT3904, SOT-23, LRC, GENERAL
PURPOSE AMPLIFIER
RCN003904-0008
Q14 XISTR, NPN, MMBT3904, SOT-23, LRC, GENERAL
PURPOSE AMPLIFIER
RCN003904-0008
Q15 COMPOSITE TRANSISTOR, SOT-363, MMDT4413 RCC004413-0010
Q16 COMPOSITE TRANSISTOR, SOT-363, MMDT4413 RCC004413-0010
Q17 XISTR, NPN, MMBT3904, SOT-23, LRC, GENERAL
PURPOSE AMPLIFIER
RCN003904-0008
Q18 XISTR, NPN, MMBT3904, SOT-23, LRC, GENERAL
PURPOSE AMPLIFIER
RCN003904-0008
Q19 CHIP, MOSFET, 2N7002, SOT-23, N-CHANNEL RCM207002-1001
Q20 CHIP, MOSFET, 2N7002, SOT-23, N-CHANNEL RCM207002-1001
Q21 XISTR, NPN, MMBT3904, SOT-23, LRC, GENERAL
PURPOSE AMPLIFIER
RCN003904-0008
Q22 SMD, MOSFET, N-CH, SOT-363, 2N7002DW,
FAIRCHILD
RCM027002-1001
Q23 SMD, MOSFET, N-CH, SOT-363, 2N7002DW,
FAIRCHILD
RCM027002-1001
Q24 SMD, MOSFET, N-CH, SOT-363, 2N7002DW,
FAIRCHILD
RCM027002-1001
Q25 SMD, MOSFET, N-CH, SOT-363, 2N7002DW,
FAIRCHILD
RCM027002-1001
Q26 CHIP, XISTR, 3P, PNP, MMBT3906, PNP, SOT23 RCP003906-0002
Q27 SMD, MOSFET, N-CH, SOT-363, 2N7002DW,
FAIRCHILD
RCM027002-1001
Q28 COMPOSITE TRANSISTOR, SOT-363, MMDT4413 RCC004413-0010
Q29 COMPOSITE TRANSISTOR, SOT-363, MMDT4413 RCC004413-0010
Q30 CHIP, MOSFET, 2N7002, SOT-23, N-CHANNEL RCM207002-1001
Q31 CHIP, MOSFET, 2N7002, SOT-23, N-CHANNEL RCM207002-1001
Q32 XISTR, NPN, MMBT3904, SOT-23, LRC, GENERAL
PURPOSE AMPLIFIER
RCN003904-0008
Q33 XISTR, NPN, MMBT3904, SOT-23, LRC, GENERAL
PURPOSE AMPLIFIER
RCN003904-0008
Q34 XISTR, NPN, MMBT3904, SOT-23, LRC, GENERAL
PURPOSE AMPLIFIER
RCN003904-0008
Q35 CHIP, XISTR, 3P, PNP, MMBT3906, PNP, SOT23 RCP003906-0002
Q36 XISTR, NPN, MMBT3904, SOT-23, LRC, GENERAL
PURPOSE AMPLIFIER
RCN003904-0008
Q37 XISTR, NPN, MMBT3904, SOT-23, LRC, GENERAL
PURPOSE AMPLIFIER
RCN003904-0008
Q38 CHIP, MOSFET, 2N7002, SOT-23, N-CHANNEL RCM207002-1001
Q39 CHIP, MOSFET, 2N7002, SOT-23, N-CHANNEL RCM207002-1001
Q40 CHIP, MOSFET, 2N7002, SOT-23, N-CHANNEL RCM207002-1001
Q41 CHIP, MOSFET, 2N7002, SOT-23, N-CHANNEL RCM207002-1001
Q42 CHIP, MOSFET, 2N7002, SOT-23, N-CHANNEL RCM207002-1001
Q43 CHIP, MOSFET, 2N7002, SOT-23, N-CHANNEL RCM207002-1001
Q44 CHIP, MOSFET, 2N7002, SOT-23, N-CHANNEL RCM207002-1001

Bose F1 812 Specifications

General

Type	Powered Speaker
Power Rating	1000W
Maximum SPL	132 dB
Dimensions	664 x 334 x 372 mm
Weight	20.2 kg
LF Driver Size	12"
Enclosure Material	Composite
Inputs	2 x XLR-1/4" combo
Outputs	XLR
Mounting Options	Pole mount
HF Driver Size	8 x 2.25" high-output mid-high drivers
