Bose F1 812 Service Manual

49
ELECTRICAL PART LIST
F1 Model 812 Input-Output / DSP PCB Assembly
Integrated Circuits
Miscellaneous
Reference
Designator
Description
V
endor Part
Number
Note
IC1 DC-DC CONVERTER, TI, TPS54331DR, SOIC8 RCI054331-0001
U1 IC, OP AMP, DUAL, 8P, SO-8, NJM2068 RCI002068-0001
U2 IC, OP AMP, DUAL, 8P, SO-8, NJM2068 RCI002068-0001
U3 IC, OP AMP, DUAL, 8P, SO-8, NJM4580 RCI004580-0001
U4 IC, OP AMP, DUAL, 8P, SO-8, NJM4580 RCI004580-0001
U5 IC, OP AMP, DUAL, 8P, SO-8, NJM4580 RCI004580-0001
U6 IC, OP AMP, DUAL, 8P, SO-8, NJM4580 RCI004580-0001
U7 IC, OP AMP, DUAL, 8P, SO-8, NJM2068 RCI002068-0001
U8 IC, CODEC, 28P, TSSOP, CS4272, 24-BIT, 192 KHZ,
STEREO AUDIO
RCI004272-0001
U9 GP, IC, 48P, ADAU1701JSTZ-RL, DSP, LQFP48,
3910920, ANALOG DEVICES
RCI001701-0001
U10 IC, SO8-W, AT24C64D, 1.7V?5.5V, Atmel, EEPROM,
64K
RCI002464-0001
U11 IC, MPU, SUPERVISORY, SOT23, MAX809, 2.93V RCI000809-0001
U12 IC, REGULATOR, ST, L7815CV, 1A, TO-220 RHI007815-1001
U13 GP, IC, 3P, UTC, LD1117AL-3.3,1A, LOW, DROPOUT,
POSITIVE, VOL
RCI111733-1102
U14 IC, REGULATOR, ST, L7915CV, 1A, TO-220 RHI007915-1001
U15 IC, OP AMP, DUAL, 8P, SO-8, NJM4580 RCI004580-0001
U16 IC, 3P, UTC, LD1117AL-5.0, SOT-223,800MA, LOW-
DROPOUT REGULATOR
RCI111750-0001
Reference
Designator
Description
V
endor Part
Number
Note
CON1 XLR Connectors, 6P, NCJ6FAV-0, 25*25*24MM CJDA06401-1010
CON2 6.35mm, Switched, Jack, Socket, Plastic, BLK,M9.4, X,
0.75, X, 23MM
CJMA63502-4010
CON3 RCA JACK, 3P, RED/WHITE, AV2-8.4-23A, STAND
NICKEL
CJRA02401-0010
CON4 XLR Connectors, 3P, NC3MAAV, 19.8*9.8*24MM CJDA03401-1010
J1 CONNECTOR, 3 PIN, P=2.5, White, 90', Normal CCN250000-0503
J2 CONN, 6 PIN, P=2.5, RED, 90', Normal CCN250010-0506
J3 CONNECTOR, 10 PIN, P=2.5, White, 90', Normal CCN250000-0510
SW1 SLIDE SWITCH, 2P/2T, SS-22F20, 17*7.5MM MSWA04018-
0010
SW2 SLIDE SWITCH, 2P/2T, SS-22F20, 17*7.5MM MSWA04018-
0010
SW3 SLIDE SWITCH, 2P/3T, SS-23E03, 20*9.3MM MSWA04017-
0010
SW4 SMD, TACT SWITCH, SOY-164BST MCWA06011-
0010
VR1 POT, ROTARY, 25MM, RV110CF-40-25A-10A10K-0C,
12 O'CLOCK POSITION DETENT, WITH, SC
MVRA02308-1031
VR2 POT, ROTARY, 10KCX2, RV112BCF-40-25A-10C10K-
0C, 12 O'CLOCK POSITION DETENT, WITH SC
MVRA02304-1031
Y1 CRYSTAL, CITIZEN: CM309S24.576MABJTR, 30ppm,
24.576MHZ, L12.5XW4.6XH3.7MM
JCQ003001-2461
- AC POWER JACK, BLACK, JR-101, 50*21.9mm CJPA11002-0010 3

Bose F1 812 Specifications

General

Type	Powered Speaker
Power Rating	1000W
Maximum SPL	132 dB
Dimensions	664 x 334 x 372 mm
Weight	20.2 kg
LF Driver Size	12"
Enclosure Material	Composite
Inputs	2 x XLR-1/4" combo
Outputs	XLR
Mounting Options	Pole mount
HF Driver Size	8 x 2.25" high-output mid-high drivers
