Bose F1 812 Service Manual

50
ELECTRICAL PART LIST
F1 Model 812 Input-Output / DSP PCB Assembly
Miscellaneous (continued)
Reference
Designator
Description
V
endor Part
Number
Note
- KNOB, VOLUME, TPE, natural black, H19xOD12 BPKA05082-0001
- SLIDE, SWITCH CAP, ABS, Kingfa, GAR, L20xW19xH9 BPOA00090-0001
- PUSH+LEVER, SWITCH, RF-1003-
BBC8E2L1C,22.1*22.5*15MM
MSWA09001-
0010
3
- LIGHT GUIDE, LED/I/O, PC+5%, TiO,
L29.6xW16.8xH7.3
BPSA02086-0001
- DOUBLE SIDED TAPE, W10mmxL50M/RL, WHITE,
T4000
XAD050010-0001
- MH DSP REAR PLATE, AL1015,
L200.24XW145.25XT2.5
GALA00612-0001
- PC Sheet, Black, L5.4XW3.8XT0.8MM, ADHESIVE,
DS11
IVHA15099-0001
-
Gasket 2, For DSP, MH, EVA, 38ｰ, 2,L135.3xW11xT2
IVEA00775-0001
- Gasket 3, 38 degree, Natural Black, L143.2xW19xT2 IVEA00693-0002
- Gasket, EVA, 38 degree, Natural black, L174.5xW7.9xT2 IVEA00697-0001
- Gasket, EVA, 38 degree, Natural Black,
L5.4XW3.8XT2.0, ADHESIVE, DS11
IVEA00887-0001
- GROUNDING WIRE, UL1007#18, YEL&GREEN,
120mm, A=OD8.0*ID4.2MM,B=STRIP, 5MM
VWP070001-0010 3
- STRAND WIRE, UL1617, 18AWG, BLUE, 100mm,
A/B=STR, 5MM
VWR0317BB-
0100
3
- STRAND WIRE, UL1617, 18AWG, BROWN, 100mm,
A/B=STR, 5MM
VWR0312BB-
0100
3
- HEAT SHRINK, TUBE, ID5.0xT0.5xL22mm, BLACK DTB005015-0220 3
-
Jack, Nut, SUS, Zinc, Black+CED Coating, 3/8ﾗ32W
HNTA64130-4240
- NUT, M3.0x0.5P, NICKEL PLATED STEEL HNT009540-1230
- Screw, M3.0x0.5PxL12, Zinc+CED Coating, SUS, PAN,
HEAD, TYPE B, FREARSON, 300HRS
HSPA63083-3121
- SCREW, M3x0.5PxL8mm, NICKEL PLATED, PAN,
HEAD
HSPA43083-1080
- Screw, T3.0x1.058PxL10, Zinc+CED Coating, PAN,
HEAD, TYPE B, FREARSON, SUS
HSPA50343-3100
- Washer, Stanless SteeL, Zinc, Black+CED, BLK,
OD14XID10XT0.5
HWSA11410-4056

Bose F1 812 Specifications

General

Type	Powered Speaker
Power Rating	1000W
Maximum SPL	132 dB
Dimensions	664 x 334 x 372 mm
Weight	20.2 kg
LF Driver Size	12"
Enclosure Material	Composite
Inputs	2 x XLR-1/4" combo
Outputs	XLR
Mounting Options	Pole mount
HF Driver Size	8 x 2.25" high-output mid-high drivers
