Bose F1 812 Service Manual

52
Resistors (continued)
ELECTRICAL PART LIST
Reference
Designator
Description
V
endor Part
Number
Note
R49 GP, CHIP, RES, 649 OHM, 1/10W, 1%, 0603 QCF011030-6490
R50 GP, CHIP, RES, 2K OHM, 1/10W, 1%, 0603 QCF011030-2001
R51 GP, CHIP, RES, 0 OHM, 1/10W, 5%, 0603 QCF015030-0000
R52 GP, CHIP, RES, 3.3K OHM, 1/10W, 1%, 0603 QCF011030-3301
R53 GP, CHIP, RES, 1K OHM, 1%, 1/10W, 0603 QCF011030-1001
R54 GP, CHIP, RES, 20K OHM, 1/10W, 1%, 0603 QCF011030-2002
R55 GP, CHIP, RES, 3.3K OHM, 1/10W, 1%, 0603 QCF011030-3301
R56 GP, CHIP, RES, 150 OHM, 1%, 1/10W, 0603 QCF011030-1500
R57 CHIP, RES, 9.1K OHM, 1/8W, 1%, 0805 QCF081020-9101
R58 GP, CHIP, RES, 0 OHM, 1/10W, 5%, 0603 QCF015030-0000
R59 CHIP, RES, 9.1K OHM, 1/8W, 1%, 0805 QCF081020-9101
R60 GP, CHIP, RES, 20K OHM, 1/10W, 1%, 0603 QCF011030-2002
R61 CHIP, RES, 51 OHM, 1%, 1/10W, 0603 QCF011030-5109
R62 CHIP, RES, 51 OHM, 1%, 1/10W, 0603 QCF011030-5109
R63 GP, CHIP, RES, 47K OHM, 1/10W, 1%, 0603 QCF011030-4702
R64 GP, CHIP, RES, 47K OHM, 1/10W, 1%, 0603 QCF011030-4702
R65 GP, CHIP, RES, 10K OHM, 1%, 1/10W, 0603 QCF011030-1002
R66 CHIP, RES, 470 OHM, 1/10W, 1%, 0603 QCF011030-4700
R67 GP, CHIP, RES, 10K OHM, 1%, 1/10W, 0603 QCF011030-1002
R68 GP, CHIP, RES, 18K OHM, 1/10W, 1%, 0603 QCF011030-1802
R69 GP, CHIP, RES, 10K OHM, 1%, 1/10W, 0603 QCF011030-1002
R70 GP, CHIP, RES, 1M OHM, 1%, 1/10W, 0603 QCF011030-1004
R71 GP, CHIP, RES, 75 OHM, 1/10W, 1%, 0603 QCF011030-7509
R72 CHIP, RES, 3.9K OHM, 1/10W, 1%, 0603 QCF011030-3901
R73 GP, CHIP, RES, 47K OHM, 1/10W, 1%, 0603 QCF011030-4702
R74 GP, CHIP, RES, 4.7K OHM, 1/10W, 1%, 0603 QCF011030-4701
R75 GP, CHIP, RES, 2.4K OHM, 1/10W, 1%, 0603 QCF011030-2401
R76 CHIP, RES, 3.9K OHM, 1/10W, 1%, 0603 QCF011030-3901
R77 GP, CHIP, RES, 47K OHM, 1/10W, 1%, 0603 QCF011030-4702
R78 GP, CHIP, RES, 2.2K OHM, 1/10W, 1%, 0603 QCF011030-2201
R79 GP, CHIP, RES, 75 OHM, 1/10W, 1%, 0603 QCF011030-7509
R80 GP, CHIP, RES, 2.2K OHM, 1/10W, 1%, 0603 QCF011030-2201
R81 GP, CHIP, RES, 2.4K OHM, 1/10W, 1%, 0603 QCF011030-2401
R82 GP, CHIP, RES, 2.2K OHM, 1/10W, 1%, 0603 QCF011030-2201
R83 GP, CHIP, RES, 3.3K OHM, 1/10W, 1%, 0603 QCF011030-3301
R84 GP, CHIP, RES, 75 OHM, 1/10W, 1%, 0603 QCF011030-7509
R85 GP, CHIP, RES, 3.3K OHM, 1/10W, 1%, 0603 QCF011030-3301
R86 GP, CHIP, RES, 47K OHM, 1/10W, 1%, 0603 QCF011030-4702
R87 CHIP, RES, 3.9K OHM, 1/10W, 1%, 0603 QCF011030-3901
R88 GP, CHIP, RES, 2.4K OHM, 1/10W, 1%, 0603 QCF011030-2401
R89 GP, CHIP, RES, 0 OHM, 1/8W, 5%, 0805 QCF085020-0000
R90 GP, CHIP, RES, 10K OHM, 1%, 1/10W, 0603 QCF011030-1002
R91 CHIP, RES, 330K OHM, 1/10W, 1%, 0603 QCF011030-3303
R92 CHIP, RES, 1.3K OHM, 1%, 1/10W, 0603 QCF011030-1301
R93 GP, CHIP, RES, 15K OHM, 1%, 1/10W, 0603 QCF011030-1502
R94 CHIP, RES, 51K OHM, 1/10W, 1%, 0603 QCF011030-5102
R95 GP, CHIP, RES, 1K OHM, 1/8W, 1%, 0805 QCF081020-1001
R96 GP, CHIP, RES, 200 OHM, 1/8W, 1%, 0805 QCF081020-2000
R97 GP, CHIP, RES, 5.1K OHM, 1%, 1/10W, 0603 QCF011030-5101
R98 GP, CHIP, RES, 5.1K OHM, 1%, 1/10W, 0603 QCF011030-5101
R99 GP, CHIP, RES, 10K OHM, 1%, 1/10W, 0603 QCF011030-1002
R100 GP, CHIP, RES, 10K OHM, 1%, 1/10W, 0603 QCF011030-1002
F1 Subwoofer Input-Output / DSP PCB Assembly

Bose F1 812 Specifications

General

Type	Powered Speaker
Power Rating	1000W
Maximum SPL	132 dB
Dimensions	664 x 334 x 372 mm
Weight	20.2 kg
LF Driver Size	12"
Enclosure Material	Composite
Inputs	2 x XLR-1/4" combo
Outputs	XLR
Mounting Options	Pole mount
HF Driver Size	8 x 2.25" high-output mid-high drivers
