Bose F1 812 Service Manual

53
Resistors (continued)
ELECTRICAL PART LIST
Reference
Designator
Description
V
endor Part
Number
Note
R101 GP, CHIP, RES, 5.1K OHM, 1%, 1/10W, 0603 QCF011030-5101
R102 GP, CHIP, RES, 20K OHM, 1/10W, 1%, 0603 QCF011030-2002
R103 GP, CHIP, RES, 100K OHM, 1%, 1/10W, 0603 QCF011030-1003
R104 GP, CHIP, RES, 1K OHM, 1%, 1/10W, 0603 QCF011030-1001
R105 GP, CHIP, RES, 5.1K OHM, 1%, 1/10W, 0603 QCF011030-5101
R106 GP, CHIP, RES, 20K OHM, 1/10W, 1%, 0603 QCF011030-2002
R107 GP, CHIP, RES, 1M OHM, 1%, 1/10W, 0603 QCF011030-1004
R108 GP, CHIP, RES, 10K OHM, 1%, 1/10W, 0603 QCF011030-1002
R109 CHIP, RES, 330K OHM, 1/10W, 1%, 0603 QCF011030-3303
R110 GP, CHIP, RES, 47K OHM, 1/10W, 1%, 0603 QCF011030-4702
R111 GP, CHIP, RES, 2.2K OHM, 1/8W, 5%, 0805 QCF085020-2220
R112 CHIP, RES, 330K OHM, 1/10W, 1%, 0603 QCF011030-3303
R113 GP, CHIP, RES, 5.1K OHM, 1%, 1/10W, 0603 QCF011030-5101
R114 GP, CHIP, RES, 2.2K OHM, 1/8W, 5%, 0805 QCF085020-2220
R115 GP, CHIP, RES, 47K OHM, 1/10W, 1%, 0603 QCF011030-4702
R116 GP, CHIP, RES, 20K OHM, 1/10W, 1%, 0603 QCF011030-2002
R117 CHIP, RES, 330K OHM, 1/10W, 1%, 0603 QCF011030-3303
R118 GP, CHIP, RES, 1/10W, 1%, 100 OHM, 0603 QCF011030-1000
R119 GP, CHIP, RES, 47K OHM, 1/10W, 1%, 0603 QCF011030-4702
R120 GP, CHIP, RES, 200 OHM, 1/8W, 1%, 0805 QCF081020-2000
R121 CHIP, RES, 270 OHM, 1/8W, 1%, 0805 QCF081020-2700
R122 CHIP, RES, 330K OHM, 1/10W, 1%, 0603 QCF011030-3303
R123 GP, CHIP, RES, 47K OHM, 1/10W, 1%, 0603 QCF011030-4702
R124 GP, CHIP, RES, 47K OHM, 1/10W, 1%, 0603 QCF011030-4702
R125 GP, CHIP, RES, 2K OHM, 1/10W, 1%, 0603 QCF011030-2001
R126 GP, CHIP, RES, 10K OHM, 1%, 1/10W, 0603 QCF011030-1002
R127 GP, CHIP, RES, 150 OHM, 1%, 1/10W, 0603 QCF011030-1500
R128 GP, CHIP, RES, 47K OHM, 1/10W, 1%, 0603 QCF011030-4702
R129 GP, CHIP, RES, 47K OHM, 1/10W, 1%, 0603 QCF011030-4702
R130 CHIP, RES, 330K OHM, 1/10W, 1%, 0603 QCF011030-3303
R131 CHIP, RES, 330K OHM, 1/10W, 1%, 0603 QCF011030-3303
R132 GP, CHIP, RES, 47K OHM, 1/10W, 1%, 0603 QCF011030-4702
R133 GP, CHIP, RES, 2K OHM, 1/10W, 1%, 0603 QCF011030-2001
R134 GP, CHIP, RES, 2K OHM, 1/10W, 1%, 0603 QCF011030-2001
R135 GP, CHIP, RES, 2K OHM, 1/10W, 1%, 0603 QCF011030-2001
R136 GP, CHIP, RES, 2K OHM, 1/10W, 1%, 0603 QCF011030-2001
R138 GP, CHIP, RES, 75 OHM, 1/10W, 1%, 0603 QCF011030-7509
R148 GP, CHIP, RES, 1K OHM, 1%, 1/10W, 0603 QCF011030-1001
R149 GP, CHIP, RES, 1K OHM, 1%, 1/10W, 0603 QCF011030-1001
R151 CHIP, RES, 3.9K OHM, 1/10W, 1%, 0603 QCF011030-3901
R152 GP, CHIP, RES, 5.1K OHM, 1%, 1/10W, 0603 QCF011030-5101
R153 GP, CHIP, RES, 47K OHM, 1/10W, 1%, 0603 QCF011030-4702
R154 GP, CHIP, RES, 100K OHM, 1%, 1/10W, 0603 QCF011030-1003
R155 GP, CHIP, RES, 5.1K OHM, 1%, 1/10W, 0603 QCF011030-5101
R156 GP, CHIP, RES, 100K OHM, 1%, 1/10W, 0603 QCF011030-1003
R157 GP, CHIP, RES, 100K OHM, 1%, 1/10W, 0603 QCF011030-1003
R158 GP, CHIP, RES, 100K OHM, 1%, 1/10W, 0603 QCF011030-1003
R159 GP, CHIP, RES, 100K OHM, 1%, 1/10W, 0603 QCF011030-1003
R160 GP, CHIP, RES, 47K OHM, 1/10W, 1%, 0603 QCF011030-4702
R161 GP, CHIP, RES, 100K OHM, 1%, 1/10W, 0603 QCF011030-1003
R163 GP, CHIP, RES, 100K OHM, 1%, 1/10W, 0603 QCF011030-1003
R164 GP, CHIP, RES, 1M OHM, 1%, 1/10W, 0603 QCF011030-1004
F1 Subwoofer Input-Output / DSP PCB Assembly
