Bose F1 812 Service Manual

54
Resistors (continued)
ELECTRICAL PART LIST
Reference
Designator
Description
V
endor Part
Number
Note
R165 GP, CHIP, RES, 100K OHM, 1%, 1/10W, 0603 QCF011030-1003
R166 GP, CHIP, RES, 2.4K OHM, 1/10W, 1%, 0603 QCF011030-2401
R167 GP, CHIP, RES, 3.3K OHM, 1/10W, 1%, 0603 QCF011030-3301
R168 GP, CHIP, RES, 3.3K OHM, 1/10W, 1%, 0603 QCF011030-3301
R169 CHIP, RES, 3.9K OHM, 1/10W, 1%, 0603 QCF011030-3901
R170 GP, CHIP, RES, 2.4K OHM, 1/10W, 1%, 0603 QCF011030-2401
R171 CHIP, RES, 3.9K OHM, 1/10W, 1%, 0603 QCF011030-3901
R172 GP, CHIP, RES, 2.4K OHM, 1/10W, 1%, 0603 QCF011030-2401
R173 GP, CHIP, RES, 3.3K OHM, 1/10W, 1%, 0603 QCF011030-3301
R174 GP, CHIP, RES, 3.3K OHM, 1/10W, 1%, 0603 QCF011030-3301
R175 CHIP, RES, 3.9K OHM, 1/10W, 1%, 0603 QCF011030-3901
R176 GP, CHIP, RES, 2.4K OHM, 1/10W, 1%, 0603 QCF011030-2401
R177 CHIP, RES, 3.9K OHM, 1/10W, 1%, 0603 QCF011030-3901
R178 GP, CHIP, RES, 2.4K OHM, 1/10W, 1%, 0603 QCF011030-2401
R179 GP, CHIP, RES, 3.3K OHM, 1/10W, 1%, 0603 QCF011030-3301
R183 GP, CHIP, RES, 1K OHM, 1%, 1/10W, 0603 QCF011030-1001
R185 GP, CHIP, RES, 47K OHM, 1/10W, 1%, 0603 QCF011030-4702
R186 GP, CHIP, RES, 1M OHM, 1%, 1/10W, 0603 QCF011030-1004
Capacitors
F1 Subwoofer Input-Output / DSP PCB Assembly
Reference
Designator
Description
V
endor Part
Number
Note
C1 GP, CHIP, CAP, 5%, 50V, 0603, 220pF, TYPE NPO PXL410370-2210
C2 CAP, MINIT, ELECT, 100uF, 16V, 20%, 105', 5x7,
P=2mm
PLE999540-1010
C3 GP, CHIP, CAP, 5%, 50V, 0603, 220pF, TYPE NPO PXL410370-2210
C4 GP, CHIP, CAP, 470pF, 50V, 5%, 0603, NPO PXL410370-4710
C5 GP, CHIP, CAP, 5%, 50V, 0603, 220pF, TYPE NPO PXL410370-2210
C6 GP, CHIP, CAP, 470pF, 50V, 5%, 0603, NPO PXL410370-4710
C7 CAP, MINIT, ELECT, 100uF, 16V, 20%, 105', 5x7,
P=2mm
PLE999540-1010
C8 GP, CHIP, CAP, 5%, 50V, 0603, 220pF, TYPE NPO PXL410370-2210
C9 CAP, MINIT, ELECT, 100uF, 16V, 20%, 105', 5x7,
P=2mm
PLE999540-1010
C10 GP, CHIP, CAP, 470pF, 50V, 5%, 0603, NPO PXL410370-4710
C11 GP, CHIP, CAP, 470pF, 50V, 5%, 0603, NPO PXL410370-4710
C12 CAP, MINIT, ELECT, 100uF, 16V, 20%, 105', 5x7,
P=2mm
PLE999540-1010
C13 GP, CHIP, CAP, 470pF, 50V, 5%, 0603, NPO PXL410370-4710
C14 CAP, MINIT, ELECT, 100uF, 16V, 20%, 105', 5x7,
P=2mm
PLE999540-1010
C15 CHIP, CAP, 18pF, 50V, 5%, 0603, TYPE NPO PXL410370-1800
C16 GP, CHIP, CAP, 0.1uF, 50V, 10%, 0603, TYPE X7R PXL456470-1040
C17 GP, CHIP, CAP, 0.1uF, 50V, 10%,, 0805, TYPE X7R PYL456470-1040
C18 GP, CHIP, CAP, 3300pF, 50V, 5%,, 0603, TYPE NPO PXL410370-3320
C19 GP, CHIP, CAP, 470pF, 50V, 5%, 0603, NPO PXL410370-4710
C20 GP, CHIP, CAP, 0.1uF, 50V, 10%,, 0805, TYPE X7R PYL456470-1040
C200 GP, CHIP, CAP, 0.1uF, 50V, 10%, 0603, TYPE X7R PXL456470-1040
C21 CHIP, CAP, 10uF, 16V, 10%, 0805, X7R PYL456440-1060
C22 CHIP, CAP, 1uF, 10V, 10%, 0603, TYPE X7R PXL456430-1050
C23 CAP, METAL, MINIATURE, BOX, 5%, 100V, 0.1uF,
P=5MM, MEM104J100A51
PLN1373A0-1040

Bose F1 812 Specifications

General

Type	Powered Speaker
Power Rating	1000W
Maximum SPL	132 dB
Dimensions	664 x 334 x 372 mm
Weight	20.2 kg
LF Driver Size	12"
Enclosure Material	Composite
Inputs	2 x XLR-1/4" combo
Outputs	XLR
Mounting Options	Pole mount
HF Driver Size	8 x 2.25" high-output mid-high drivers
