Bose F1 812 Service Manual

55
ELECTRICAL PART LIST
Capacitors (continued)
F1 Subwoofer Input-Output / DSP PCB Assembly
Reference
Designator
Description
V
endor Part
Number
Note
C24 CAP, MINIT, ELECT, 100uF, 16V, 20%, 105', 5x7,
P=2mm
PLE999540-1010
C25 CAP, METAL, MINIATURE, BOX, 5%, 100V, 0.1uF,
P=5MM, MEM104J100A51
PLN1373A0-1040
C26 GP, CHIP, CAP, 470pF, 50V, 5%, 0603, NPO PXL410370-4710
C27 CHIP, CAP, 18pF, 50V, 5%, 0603, TYPE NPO PXL410370-1800
C28 CAP, METAL, MINIATURE, BOX, 5%, 100V, 0.1uF,
P=5MM, MEM104J100A51
PLN1373A0-1040
C29 CAP, METAL, MINIATURE, BOX, 5%, 100V, 0.1uF,
P=5MM, MEM104J100A51
PLN1373A0-1040
C30 GP, CHIP, CAP, 3300pF, 50V, 5%,, 0603, TYPE NPO PXL410370-3320
C31 GP, CHIP, CAP, 0.1uF, 50V, 10%,, 0805, TYPE X7R PYL456470-1040
C32 GP, CHIP, CAP, 470pF, 50V, 5%, 0603, NPO PXL410370-4710
C33 CAP, ELECT, 10uF, 50V, 20%, 105', 5x11mm, P=2.5,
A/I
PME099570-1000
C34 GP, CHIP, CAP, 0.1uF, 50V, 10%,, 0805, TYPE X7R PYL456470-1040
C35 CAP, METAL, MINIATURE, BOX, 5%, 100V, 0.1uF,
P=5MM, MEM104J100A51
PLN1373A0-1040
C36 CAP, METAL, MINIATURE, BOX, 5%, 100V, 0.1uF,
P=5MM, MEM104J100A51
PLN1373A0-1040
C37 CAP, METAL, MINIATURE, BOX, 5%, 100V, 0.1uF,
P=5MM, MEM104J100A51
PLN1373A0-1040
C38 GP, CHIP, CAP, 0.1uF, 50V, 10%, 0603, TYPE X7R PXL456470-1040
C39 GP, CHIP, CAP, 0.1uF, 50V, 10%, 0603, TYPE X7R PXL456470-1040
C40 GP, CHIP, CAP, 0.1uF, 50V, 10%, 0603, TYPE X7R PXL456470-1040
C41 GP, CHIP, CAP, 0.1uF, 50V, 10%, 0603, TYPE X7R PXL456470-1040
C42 GP, CHIP, CAP, 0.1uF, 50V, 10%, 0603, TYPE X7R PXL456470-1040
C43 GP, CHIP, CAP, 0.1uF, 50V, 10%, 0603, TYPE X7R PXL456470-1040
C44 GP, CHIP, CAP, 0.1uF, 50V, 10%, 0603, TYPE X7R PXL456470-1040
C45 GP, CHIP, CAP, 0.1uF, 50V, 10%, 0603, TYPE X7R PXL456470-1040
C46 GP, CHIP, CAP, 0.1uF, 50V, 10%, 0603, TYPE X7R PXL456470-1040
C47 GP, CHIP, CAP, 0.1uF, 50V, 10%, 0603, TYPE X7R PXL456470-1040
C48 GP, CHIP, CAP, 0.1uF, 50V, 10%, 0603, TYPE X7R PXL456470-1040
C49 GP, CHIP, CAP, 0.1uF, 50V, 10%, 0603, TYPE X7R PXL456470-1040
C50 GP, CHIP, CAP, 0.1uF, 50V, 10%, 0603, TYPE X7R PXL456470-1040
C51 CHIP, ELECT, 10uF, 16V, SMD, 4x4mm PBE099540-1000
C52 GP, CHIP, CAP, 0.1uF, 50V, 10%, 0603, TYPE X7R PXL456470-1040
C53 CHIP, ELECT, 20%, 6.3V, SMD, -40~+105'C, 47uF,
4*5MM
PBE099520-4700
C54 GP, CHIP, CAP, 0.1uF, 50V, 10%, 0603, TYPE X7R PXL456470-1040
C55 CHIP, CAP, 10uF, 6.3V, 10%, 0805, X7R PYL456420-1060
C56 CAP, MINIT, ELECT, 100uF, 35V, 20%, 105', 8x7,
P=3.5, LOW ESR
PLE999560-1010
C57 GP, CHIP, CAP, 0.1uF, 50V, 10%, 0603, TYPE X7R PXL456470-1040
C58 CHIP, CAP, 1uF, 10V, 10%, 0603, TYPE X7R PXL456430-1050
C59 GP, CHIP, CAP, 0.1uF, 50V, 10%, 0603, TYPE X7R PXL456470-1040
C60 GP, CHIP, CAP, 0.1uF, 50V, 10%, 0603, TYPE X7R PXL456470-1040
C61 GP, CHIP, CAP, 0.1uF, 50V, 10%, 0603, TYPE X7R PXL456470-1040
C62 GP, CHIP, CAP, 3.3nF, 50V, 10%, 0603, X7R PXL456470-3320
C63 GP, CHIP, CAP, 56nF, 50V, 10%, 0603, X7R PXL456470-5630
C64 GP, CHIP, CAP, 22pF, 50V, 5%, 0603, TYPE NPO PXL410370-2200
C65 GP, CHIP, CAP, 680pF, 50V, 5%, 0603, NPO PXL410370-6810
