Bose F1 812 Service Manual

56
ELECTRICAL PART LIST
Capacitors (continued)
F1 Subwoofer Input-Output / DSP PCB Assembly
Reference
Designator
Description
V
endor Part
Number
Note
C66 GP, CHIP, CAP, 22pF, 50V, 5%, 0603, TYPE NPO PXL410370-2200
C67 CHIP, CAP, 390pF, 50V, 10%, 0603, X7R PXL456470-3910
C68 CHIP, ELECT, 10uF, 16V, SMD, 4x4mm PBE099540-1000
C69 GP, CHIP, CAP, 0.1uF, 50V, 10%, 0603, TYPE X7R PXL456470-1040
C70 CHIP, CAP, 1000pF, 50V, 5%, 0603, TYPE NPO PXL410370-1020
C71 CAP, ELECT, 20%, 25V, 100uF, L=3.5mm, 105' PVE099550-1010
C72 GP, CHIP, CAP, 820pF, 50V, 5%,, 0603, TYPE NPO PXL410370-8210
C73 CHIP, CAP, 10uF, 6.3V, 10%, 0805, X7R PYL456420-1060
C74 GP, CHIP, CAP, 0.1uF, 50V, 10%, 0603, TYPE X7R PXL456470-1040
C75 CHIP, CAP, 10uF, 16V, 10%, 0805, X7R PYL456440-1060
C76 GP, CHIP, CAP, 0.1uF, 50V, 10%, 0603, TYPE X7R PXL456470-1040
C77 CHIP, CAP, 1000pF, 50V, 5%, 0603, TYPE NPO PXL410370-1020
C78 CAP, MINIT, ELECT, 100uF, 35V, 20%, 105', 8x7,
P=3.5, LOW ESR
PLE999560-1010
C79 CAP, MINIT, ELECT, 100uF, 35V, 20%, 105', 8x7,
P=3.5, LOW ESR
PLE999560-1010
C80 CAP, ELECT, 47uF, 16V, 20%, 105'C, 5x11xP2 PLE099542-4700
C81 GP, CHIP, CAP, 0.1uF, 50V, 10%, 0603, TYPE X7R PXL456470-1040
C82 GP, CHIP, CAP, 0.1uF, 50V, 10%, 0603, TYPE X7R PXL456470-1040
C83 GP, CHIP, CAP, 0.1uF, 50V, 10%, 0603, TYPE X7R PXL456470-1040
C84 CAP, ELECT, 220uF, 25V, 20%, 8x12x4mm, 105'C,
AI-RADIAL
PME099550-2210
C85 GP, CHIP, CAP, 0.1uF, 50V, 10%, 0603, TYPE X7R PXL456470-1040
C86 GP, CHIP, CAP, 0.1uF, 50V, 10%, 0603, TYPE X7R PXL456470-1040
C87 CHIP, CAP, 10uF, 16V, 10%, 0805, X7R PYL456440-1060
C88 CAP, ELECT, 470uF, 25V, 20%, 8x14mm, P=3.5mm,
D10MM, -25'C + 105'C, 3.5MM
PVE099550-4710
C89 CHIP, CAP, 10uF, 16V, 10%, 0805, X7R PYL456440-1060
C90 GP, CHIP, CAP, 0.1uF, 50V, 10%, 0603, TYPE X7R PXL456470-1040
C91 CAP, ELECT, 470uF, 25V, 20%, 8x14mm, P=3.5mm,
D10MM, -25'C + 105'C, 3.5MM
PVE099550-4710
C92 GP, CHIP, CAP, 0.1uF, 50V, 10%, 0603, TYPE X7R PXL456470-1040
C93 CAP, ELECT, 220uF, 25V, 20%, 8x12x4mm, 105'C,
AI-RADIAL
PME099550-2210
C94 GP, CHIP, CAP, 68pF, 50V, 5%,, 0603, TYPE NPO PXL410370-6800
C95 GP, CHIP, CAP, 1800pF, 50V, 5%,, 0603, TYPE NPO PXL410370-1820
C96 GP, CHIP, CAP, 0.015uF, 50V, 10%,, 0603, TYPE
X7R
PXL456470-1530
C97 CHIP, CAP, 390pF, 50V, 10%, 0603, X7R PXL456470-3910
C98 GP, CHIP, CAP, 680pF, 50V, 5%, 0603, NPO PXL410370-6810
C99 CAP, MINIT, ELECT, 100uF, 35V, 20%, 105', 8x7,
P=3.5, LOW ESR
PLE999560-1010
C100 GP, CHIP, CAP, 680pF, 50V, 5%, 0603, NPO PXL410370-6810
C101 CHIP, CAP, 1000pF, 50V, 5%, 0603, TYPE NPO PXL410370-1020
C102 CHIP, ELECT, 20%, 6.3V, SMD, -40~+105'C, 47uF,
4*5MM
PBE099520-4700
C103 CHIP, CAP, 10uF, 6.3V, 10%, 0805, X7R PYL456420-1060
C104 CHIP, ELECT, 10uF, 16V, SMD, 4x4mm PBE099540-1000
C105 GP, CHIP, CAP, 0.1uF, 50V, 10%, 0603, TYPE X7R PXL456470-1040
C106 GP, CHIP, CAP, 0.1uF, 50V, 10%, 0603, TYPE X7R PXL456470-1040
C107 CHIP, ELECT, 10uF, 16V, SMD, 4x4mm PBE099540-1000
C108 CAP, ELECT, 47uF, 16V, 20%, 105'C, 5x11xP2 PLE099542-4700

Bose F1 812 Specifications

General

Type	Powered Speaker
Power Rating	1000W
Maximum SPL	132 dB
Dimensions	664 x 334 x 372 mm
Weight	20.2 kg
LF Driver Size	12"
Enclosure Material	Composite
Inputs	2 x XLR-1/4" combo
Outputs	XLR
Mounting Options	Pole mount
HF Driver Size	8 x 2.25" high-output mid-high drivers
