Bose FreeSpace IZA 2120-HZ Service Manual

103
ELECTRICAL PART LIST
Miscellaneous
FreeSpace
®
ZA 2120-LZ Rear Panel PCB Assembly
Reference
Designator
Description
V
endor Part
Number
Note
J401 5P, ST., WAFER, P=2.0, COULOMB 2102-050S+003
J402 WIRE-CONN, 6P, P2.0, #28, UL1007, L=480,
RD/WH, F/M
7013-4530+0
J403 WIRE-CONN, 4P, P2.0, #28, UL1007, L=320,
RD/WH, F/M
7013-4541+0
J404 WIRE-CONN, 7P, P2.0, #28, UL1007, L=140,
RD/WH, F/M
7013-4520+0
J405 SOCKET, M, 2P, P5, 300V, 15A, BLACK 2113-3361+1
J407 SOCKET, M, 2P, P5, 300V, 15A, BLACK 2113-3361+1
J700 RCA, JACK, F, 2P, P15, 30V, 0.3A, H=10+9.5,
R/W
2113-3153+2
J701 CONN, FFC, 10P, P0.5, SMT, ST 2101-3375+1
J702 SOCKET, M, 5P, P5, 250V, 12A, GRN, ST 2113-3421+0
SW400 SWITCH, SLIDE, DPDT, 50V, 0.5A, L=7 5200-5012+0
SW700 SWITCH, SLIDE, DPDT, 50V, 0.5A, L=7 5200-5012+0
VR400 VR, ROTARY, 20BKX1, 20%, V, L=15, 18TEETH,
CTR
4751-226E+0
VR401 VR, ROTARY, 20BKX1, 20%, V, L=15, 18TEETH,
CTR
4751-226E+0

Bose FreeSpace IZA 2120-HZ Specifications

General

Maximum current	5 A
AC input voltage	230 V
AC input frequency	50 Hz
Amplifier class	D
Frequency range	55 - 20000 Hz
Audio output channels	2.0 channels
Peak power per channel	- W
Total Harmonic Distortion (THD)	0.3 %
Purpose	Performance/stage
Equalizer	Yes
Product color	Silver
Volume control	Rotary
Connectivity technology	Wired
Line inputs (RCA)	2
Speakers connectivity type	RCA
Package weight	5400 g

Weight and Dimensions

Depth	324 mm
Width	483 mm
Height	44 mm
Weight	4100 g
