Bose FreeSpace IZA 2120-HZ Service Manual

76
ELECTRICAL PART LIST
Miscellaneous
FreeSpace
®
IZA 2120-LZ and ZA 2120-LZ SMPS PCB Assembly
Reference
Designator
Description
V
endor Part
Number
Note
CLAMP SMPS CLAMP, IC, SUS301, T=1, NATURAL, 3/4H 4136-0932
F200 FUSE, 4A, 250V, 8.5X8, EU/CCC, RLT 5120-1180 3
HEATSINK SCREW, MACHINE, BIND, HEAD, M3X8, CROSS-
RECESS, BZ
2904-3008
HS SMPS HEATSINK, SMPS, 14X30, L120, AL-EXT,
ANODIZE, BLACK
5401-0701
HS SMPS HEATSINK, SMPS, 14X30, L=70, AL-EXT,
ANODIZE, BLACK
5401-0702
HS200 HEATSINK, IC, 25.4X12.7X30, AL, PLATE,
MSMGMA100
5401-0181
J201 7, PIN, WAFER, P2.0(COULUMB) 2102-070S
J202 WAFER, 3PIN, P=3.96 2101-3065
J203 WAFER, 3P, P7.92/11.88, STRAIGHT 2101-3097
J204 JM24182-2P, WAFER 2101-9120
NTC200 THERMISTOR, NTC, 10R, 20%, 240VAC, 5A, -40-
200C, AL
5202-0028 3
NUT NUT, HEX, M3X22X5.4, YZ 2640-302
SCREW SCREW, M3X10, W/S&F, WASHER, (BLK) 2900-3010
SCREW M3 SCREW, MACHINE, PAN, M3X8, CROSS-
RECESS, BZ
2900-3008
SILICON INSULATN-SHEET, SIL-PAD, 800, 18X13 3101-0611
T200 TRANS, PWR, 385V/40V, 40W, 4A, ER40 1806-4234 3
T201 CHOKE, COMMON MODE, 10MH, MIN, 5A, AT 1805-0090 3
T202 CHOKE, COIL, 940UH, 15%, 8A, MI 1805-0520 3
T203 CHOKE, COMMON MODE, 10MH, MIN, 5A, AT 1805-0090 3
T204 TRANS, PWR, 385V, 40W, ER28 1806-4236 3
WASHER WASHER, METAL, ID, 3.3, 0D8, T=0.5 2600-3005

Bose FreeSpace IZA 2120-HZ Specifications

General

Maximum current	5 A
AC input voltage	230 V
AC input frequency	50 Hz
Amplifier class	D
Frequency range	55 - 20000 Hz
Audio output channels	2.0 channels
Peak power per channel	- W
Total Harmonic Distortion (THD)	0.3 %
Purpose	Performance/stage
Equalizer	Yes
Product color	Silver
Volume control	Rotary
Connectivity technology	Wired
Line inputs (RCA)	2
Speakers connectivity type	RCA
Package weight	5400 g

Weight and Dimensions

Depth	324 mm
Width	483 mm
Height	44 mm
Weight	4100 g
