Bose FreeSpace IZA 2120-HZ Service Manual

32
ELECTRICAL PART LIST
FreeSpace
®
IZA 2120-HZ and ZA 2120-HZ SMPS PCB Assembly
Resistors
Reference
Designator
Description
V
endo
r
Part
Number
Note
R200 RMG, 1/16W, 0R, 1%, 0603 4723-000A
R202 RMG, 1/16W, 2.2K, 1%, 0603/1608 4723-222A
R203 RMG, 1/16W, 3K, 1%, 0603 4723-302A
R204 RMG, 1/16W, 4.7K, 1%, 0603/1608 4723-472A
R206 RMG, 1/10W, 82R, 5%, 0805 4720-820J
R207 RMG, 1/8W, 330K, 5%, 1206 4721-334J
R208 RMG, 1/8W, 330K, 5%, 1206 4721-334J
R209 RMG, 1/8W, 330K, 5%, 1206 4721-334J
R210 RMG, 1/8W, 330K, 5%, 1206 4721-334J
R211 RMG, 1/8W, 330K, 5%, 1206 4721-334J
R212 RMG, 1/8W, 330K, 5%, 1206 4721-334J
R213 RMG, 1/10W, 91K, 1%, 0603 4720-913A
R214 RMG, 1/10W, 75R, 5%, 0805 4720-750J
R215 RMG, 1/4W, 200K, 1%, 1206 4725-204A
R216 RMG, 1/8W, 0R, 1%, 1206 4721-000A
R217 RMG, 1/16W, 30K, 1%, 0603/1608 4723-303A
R220 RMG, 1/8W, 1.5K, 5%, 1206 4721-152J
R221 RMG, 1/8W, 1.5K, 5%, 1206 4721-152J
R222 RMG, 1/16W, 6.2K, 1%, 0603/1608 4723-622A
R223 RMG, 1/16W, 51K, 1%, 0603/16 4723-513A
R224 RMG, 1/16W, 56K, 1%, 0603 4723-563AR
R225 RMG, 1/16W, 560K, 1%, 0603/1608 4723-564A
R226 RMG, 1/16W, 13K, 1%, 0603 4723-133AR
R227 RMG, 1/16W, 0R, 1%, 0603 4723-000A
R228 RMG, 1/10W, 15R, 1%, 0805 4720-150A
R229 RMG, 1/10W, 15R, 1%, 0805 4720-150A
R230 RMG, 1/10W, 62K, 5%, 0805 4720-623J
R232 RMG, 1/10W, 18K, 5%, 0805 4720-183J
R233 RMG, 1/4W, 100R, 1%, 1206 4725-101A
R234 RMG, 1/4W, 100R, 1%, 1206 4725-101A
R235 RMG, 1/16W, 1K, 1%, 0603/1608 4723-102A
R236 RMG, 1/16W, 1K, 1%, 0603/1608 4723-102A
R240 RMG, 1/16W, 1K, 1%, 0603/1608 4723-102A
R241 RMG, 1/16W, 1K, 1%, 0603/1608 4723-102A
R242 RMG, 1/8W, 2.2R, 5%, 1206 4721-2R2J
R243 RMG, 1/8W, 330K, 5%, 1206 4721-334J
R244 RMG, 1/8W, 330K, 5%, 1206 4721-334J
R245 RMG, 1/8W, 330K, 5%, 1206 4721-334J
R246 RMG, 1/16W, 0R, 1%, 0603 4723-000A
R248 RMG, 1/8W, 47R, 5%, 1206 4721-470J
R249 RMG, 1/8W, 47R, 5%, 1206 4721-470J
R251 RMG, 1/8W, 47R, 5%, 1206 4721-470J
R253 RMG, 1W, 20K, 5%, 2512 4728-203J
R254 RMG, 1/4W, 5.1K, 5%, 1206 4725-512J
R257 RMG, 1/4W, 5.1K, 5%, 1206 4725-512J
R262 RMG, 1/16W, 10R, 1%, 0603 4723-100AR
R263 RMG, 1/16W, 10R, 1%, 0603 4723-100AR
R264 RMG, 1/16W, 10R, 1%, 0603 4723-100AR
R265 RMG, 1/16W, 10K, 1%, 0603 4723-103AR
R266 RMG, 1/16W, 10K, 1%, 0603 4723-103AR
R267 RMG, 1W, 20K, 5%, 2512 4728-203J
R268 RMG, 1/10W, 100R, 1%, 0805 4720-101A

Bose FreeSpace IZA 2120-HZ Specifications

General

Maximum current	5 A
AC input voltage	230 V
AC input frequency	50 Hz
Amplifier class	D
Frequency range	55 - 20000 Hz
Audio output channels	2.0 channels
Peak power per channel	- W
Total Harmonic Distortion (THD)	0.3 %
Purpose	Performance/stage
Equalizer	Yes
Product color	Silver
Volume control	Rotary
Connectivity technology	Wired
Line inputs (RCA)	2
Speakers connectivity type	RCA
Package weight	5400 g

Weight and Dimensions

Depth	324 mm
Width	483 mm
Height	44 mm
Weight	4100 g
