ELECTRICAL PART LIST
Resistors (continued)
FreeSpace
®
IZA 2120-HZ and ZA 2120-HZ SMPS PCB Assembly
Capacitors
Reference
Designator
Description
V
endo
r
Part
Number
Note
R359 RMG, 1/16W, 1K, 1%, 0603/1608 4723-102A
R360 RMG, 1/16W, 1K, 1%, 0603/1608 4723-102A
R361 RMG, 1/16W, 1K, 1%, 0603/1608 4723-102A
R362 RMG, 1/16W, 47K, 1%, 0603 4723-473AR
R363 RMG, 1/8W, 4.7R, 1%, 1206 4721-4R7A
R364 RMG, 1/16W, 1K, 1%, 0603/1608 4723-102A
R365 RMG, 1/8W, 47R, 5%, 1206 4721-470J
Reference
Designator
Description
V
endo
r
Part
Number
Note
C200 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C201 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C202 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C204 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C205 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C206 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C207 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C208 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C209 CC, 50V, 1000pF, 5%, 0603, X7R 150F-102JAC
C210 CC, 50V, 1000pF, 5%, 0603, X7R 150F-102JAC
C211 CC, 50V, 1000pF, 5%, 0603, X7R 150F-102JAC
C212 CC, 50V, 1000pF, 5%, 0603, X7R 150F-102JAC
C213 CC, 50V, 120pF, 5%, 0603, C0G 150F-121JAC
C214 CE, 50V, 10uF, 20%, RLT, 5X11, 105C, RX 157F-106MIUTU
C215 CC, 25V, 10uF, 10%, 1206, 3.2X1.6, X5R 150E-106KCF
C216 CC, 25V, 10uF, 10%, 1206, 3.2X1.6, X5R 150E-106KCF
C218 CC, 50V, 0.01uF, 5%, 0603 150F-103JAC
C219 CC, 50V, 0.01uF, 5%, 0603 150F-103JAC
C220 CE, 220V, 1000uF, 20%, RL, 35X30, SNAP-105C 1576-108M^$T
C221 CE, 220V, 1000uF, 20%, RL, 35X30, SNAP-105C 1576-108M^$T
C225 CC, 500V, 0.022uF, 10%, 1206 150L-223KCF
C226 CC, 500V, 0.022uF, 10%, 1206 150L-223KCF
C227 CC, 630V, 0.1uF, 10%, 1812, X7R 150M-104KHF
C232 CC, 100V, 100pF, 10%, 0805, 1.2X2, NPO 150H-101KBD
C234 CC, 100V, 100pF, 10%, 0805, 1.2X2, NPO 150H-101KBD
C235 CC, 100V, 100pF, 10%, 0805, 1.2X2, NPO 150H-101KBD
C239 CE, 35V, 100uF, 20%, RLT, 6.3X11, 105C, LOW,
ESR
157Q-107MLUTR
C243 CC, 630V, 100pF, 5%, 1206, 3.2X1.6 150M-101JCF
C244 CC, 630V, 100pF, 5%, 1206, 3.2X1.6 150M-101JCF
C245 CC, 630V, 100pF, 5%, 1206, 3.2X1.6 150M-101JCF
C246 CC, 630V, 100pF, 5%, 1206, 3.2X1.6 150M-101JCF
C247 CC, 400V, 470pF, +20%, RL, 9.5X8.0,
AH09B471KLO
150T-471MRO 3
C248 CC, 400V, 470pF, +20%, RL, 9.5X8.0,
AH09B471KLO
150T-471MRO 3
C249 CE, 450V, 220uF, 20%, RL, 35X30, SNAP-105C 1574-227M^$T
C251 CP, 275V, 0.47uF, 20%, RB, 18X16 158Z-474M75
C252 CP, 275V, 0.47uF, 20%, RB, 18X16 158Z-474M75

Bose FreeSpace IZA 2120-HZ Specifications

General

Maximum current	5 A
AC input voltage	230 V
AC input frequency	50 Hz
Amplifier class	D
Frequency range	55 - 20000 Hz
Audio output channels	2.0 channels
Peak power per channel	- W
Total Harmonic Distortion (THD)	0.3 %
Purpose	Performance/stage
Equalizer	Yes
Product color	Silver
Volume control	Rotary
Connectivity technology	Wired
Line inputs (RCA)	2
Speakers connectivity type	RCA
Package weight	5400 g

Weight and Dimensions

Depth	324 mm
Width	483 mm
Height	44 mm
Weight	4100 g
