Bose FreeSpace IZA 2120-HZ Service Manual

36
ELECTRICAL PART LIST
Capacitors (continued)
FreeSpace
®
IZA 2120-HZ and ZA 2120-HZ SMPS PCB Assembly
Inductors
Diodes
Reference
Designator
Description
V
endor Part
Number
Note
C307 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C308 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C310 CER2, 1206, X7R, 50V, 100N, PM10, R 150F-104KCF
C311 CER2, 1206, X7R, 50V, 100N, PM10, R 150F-104KCF
C312 CC, 630V, 0.1U, 10%, 1812, X7R 150M-104KHF
C313 CC, 50V, 0.47U, 10%, 0805, 1.25X2, X7R 150F-474KBD
C314 CC, 500V, 0.022U, 10%, 1206 150L-223KCF
C315 CC, 630V, 0.1U, 10%, 1812, X7R 150M-104KHF
C318 CC, 100V, 100pF, 10%, 0805, 1.2X2, NPO 150H-101KBD
C319 CC, 50V, 0.1uF, 10%, 0805, 1.2X2.0 150F-104KBD
C320 CE, 25V, 470U, 20%, RLT, 10X16, 105C, RX,
NOVER
157E-477MS5TU
C321 CC, 50V, 0.1uF, 10%, 0805, 1.2X2.0 150F-104KBD
C322 CE, 25V, 470U, 20%, RLT, 10X16, 105C, RX,
NOVER
157E-477MS5TU
C323 CC, 50V, 0.1uF, 10%, 0805, 1.2X2.0 150F-104KBD
Reference
Designator
Description
V
endo
r
Part
Number
Note
L202 FERRITE BEAD, CHIP, SEBW201209U121MT,
0805
1808-0872
L203 FERRITE BEAD, CHIP, SEBW201209U121MT,
0805
1808-0872
L204 FERRITE BEAD, CHIP, SEBW201209U121MT,
0805
1808-0872
L205 FERRITE BEAD, CHIP, SEBW201209U121MT,
0805
1808-0872
L208 FERRITE BEAD, CHIP, SEBW201209U121MT,
0805
1808-0872
L210 FERRITE BEAD, CHIP, SEBW201209U121MT,
0805
1808-0872
L211 FERRITE BEAD, CHIP, SEBW201209U121MT,
0805
1808-0872
L212 FERRITE BEAD, INDUCTOR, BL01RN1A1F1J 1808-0680
L213 FERRITE BEAD, INDUCTOR, BL01RN1A1F1J 1808-0680
Reference
Designator
Description
V
endo
r
Part
Number
Note
BR200 DIODE, BRIDGE, 600V, 8A, GBU8J, RL 4840-9211 3
D200 DIODE, IN5408-B, 3A, 1000V 4805-4080
D201 DIODE, SCHOTTKY, SK16, DO-214AA, 60V, 1A,
SMD, PANJIT
480S-K160
D202 DIODE, SCHOTTKY, 650V, 6A, IDH06G65C5, TO-
220, RL
4806-5C50
D203 DIODE, ULTRAFAST, 600V, 16A, ER1606CT, RL,
PANJIT
4800-6CT0
D204 DIODE, ULTRAFAST, 600V, 16A, ER1606CT, RL,
PANJIT
4800-6CT0

Bose FreeSpace IZA 2120-HZ Specifications

General

Maximum current	5 A
AC input voltage	230 V
AC input frequency	50 Hz
Amplifier class	D
Frequency range	55 - 20000 Hz
Audio output channels	2.0 channels
Peak power per channel	- W
Total Harmonic Distortion (THD)	0.3 %
Purpose	Performance/stage
Equalizer	Yes
Product color	Silver
Volume control	Rotary
Connectivity technology	Wired
Line inputs (RCA)	2
Speakers connectivity type	RCA
Package weight	5400 g

Weight and Dimensions

Depth	324 mm
Width	483 mm
Height	44 mm
Weight	4100 g
