Bose FreeSpace IZA 2120-HZ Service Manual

38
ELECTRICAL PART LIST
Integrated Circuits
FreeSpace
®
IZA 2120-HZ and ZA 2120-HZ SMPS PCB Assembly
Miscellaneous
Transistors (continued)
Reference
Designator
Description
V
endo
r
Part
Number
Note
Q213 TR, 3904, HFE, 100-300, SM 4860-0640
Q214 TR, MMBTA92, PNP, SOT23, KEC 4860-5360
Q215 TR, NPN, 2SC2655Y, HFE, 40, TO-92MOD, RLT 4856-55Y0
Q216 TR, MMBTA42-7-F, NPN, SMD, SOT23 485T-A420
Reference
Designator
Description
V
endo
r
Part
Number
Note
U200 IC, DRIVER, NCP5181DR2G, SOIC-8 3132-8471
U201 IC, LM19, THERMAL, SENSOR, TO-92, NS 3132-2581
U202 IC, LM339, SMD, COMPARATORS 3132-1250
U203 PHOTOCOUPLER, EL817S1, S1 4818-17S1
U204 PHOTOCOUPLER, EL817S1, S1 4818-17S1 3
U205 PHOTOCOUPLER, EL817S1, S1 4818-17S1 3
U206 IC, REGULATOR, 5V, LM78L05ACM, SO-8 3131-3390
U207 IC, PFC, CONTROLER, IR1155S, SO8 3132-9880
U208 IC, POWER, NCP1271, SO-8, ONSEMI 3132-806111
U209 IC, LLC, SMPS, UCC25600, SOIC-8 3132-8371
U210 IC, REGULATOR, TL432BIDBZR, SOT-23-3, TI 3132-769116
U211 IC, REGULATOR, TL432BIDBZR, SOT-23-3, TI 3132-769116
U212 PHOTOCOUPLER, EL817S1, S1 4818-17S1 3
U213 IC, NJM78M05DL1A-#ZZZB, REGULATOR 3132-2101
Reference
Designator
Description
V
endor Part
Number
Note
CLAMP, SMPS CLAMP, IC, SUS301, T=1, NATURAL, 3/4H 4136-0932
F200 FUSE, 4A, 250V, 8.5X8, EU/CC, C, RLT 5120-1180 3
HEATSINK SCREW, MACHINE, BIND, HEAD, M3X8, CROSS-
RECESS, BZ
2904-3008
HS, SMPS HEATSINK, SMPS, 14X30, L120, AL-EXT,
ANODIZE, BLACK
5401-0701
HS, SMPS HEATSINK, SMPS, 14X30, L=70, AL-EXT,
ANODIZE, BLACK
5401-0702
HS200 HEATSINK, IC, 25.4X12.7X30, AL, PLATE,
MSMGMA100
5401-0181
J201 7, PIN, WAFER, P2.0(COULUMB) 2102-070S
J202 WAFER, 4P, P3.96, STRAIGHT, MALE 2101-3053
J203 WAFER, 3P, P7.92/11.88, STRAIGHT 2101-3097
J204 JM24182-2P, WAFER 2101-9120
NTC200 THERMISTOR, NTC, 10R, 20%, 240VAC, 5A, -40-
200C, AL
5202-0028 3
NUT NUT, HEX, M3X22X5.4, YZ 2640-3022

Bose FreeSpace IZA 2120-HZ Specifications

General

Maximum current	5 A
AC input voltage	230 V
AC input frequency	50 Hz
Amplifier class	D
Frequency range	55 - 20000 Hz
Audio output channels	2.0 channels
Peak power per channel	- W
Total Harmonic Distortion (THD)	0.3 %
Purpose	Performance/stage
Equalizer	Yes
Product color	Silver
Volume control	Rotary
Connectivity technology	Wired
Line inputs (RCA)	2
Speakers connectivity type	RCA
Package weight	5400 g

Weight and Dimensions

Depth	324 mm
Width	483 mm
Height	44 mm
Weight	4100 g
