Bose FreeSpace IZA 2120-HZ Service Manual

67
ELECTRICAL PART LIST
Capacitors (continued)
FreeSpace
®
ZA 2120-HZ Rear Panel PCB Assembly
Reference
Designator
Description
V
endor Part
Number
Note
C739 CT, 16V, 10U, 20%, SMD 154D-106M+3-CF
C740 CT, 16V, 10U, 20%, SMD 154D-106M+3-CF
C741 CT, 16V, 10U, 20%, SMD 154D-106M+3-CF
C742 CT, 16V, 10U, 20%, SMD 154D-106M+3-CF
C743 CT, 16V, 10U, 20%, SMD 154D-106M+3-CF
C744 CT, 16V, 10U, 20%, SMD 154D-106M+3-CF
C745 CC, 50V, 1U, 10%, 0805 150F-105K+J-BD
C746 CC, 50V, 1U, 10%, 0805 150F-105K+J-BD
C747 CC, 50V, 1U, 10%, 0805 150F-105K+J-BD
C748 CC, 50V, 1U, 10%, 0805 150F-105K+J-BD
C750 CC, 50V, 100PF, 5%, 0603, C0G 150F-101J+P-AC
C751 CC, 50V, 100PF, 5%, 0603, C0G 150F-101J+P-AC
C752 CC, 50V, 100PF, 5%, 0603, C0G 150F-101J+P-AC
C753 CC, 50V, 100PF, 5%, 0603, C0G 150F-101J+P-AC
C754 CC, 50V, 100PF, 5%, 0603, C0G 150F-101J+P-AC
C755 CC, 50V, 100PF, 5%, 0603, C0G 150F-101J+P-AC
C756 CC, 50V, 100PF, 5%, 0603, C0G 150F-101J+P-AC
C757 CC, 50V, 100PF, 5%, 0603, C0G 150F-101J+P-AC
C758 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104K+P-AC
C759 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104K+P-AC
C760 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104K+P-AC
C761 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104K+P-AC
C764 CT, 16V, 10U, 20%, SMD 154D-106M+3-CF
C765 CT, 16V, 10U, 20%, SMD 154D-106M+3-CF
C766 CT, 16V, 10U, 20%, SMD 154D-106M+3-CF
C767 CT, 16V, 10U, 20%, SMD 154D-106M+3-CF
C768 CT, 16V, 10U, 20%, SMD 154D-106M+3-CF
C769 CT, 16V, 10U, 20%, SMD 154D-106M+3-CF
C770 CC, 50V, 100PF, 5%, 0603, C0G 150F-101J+P-AC
C771 CC, 50V, 100PF, 5%, 0603, C0G 150F-101J+P-AC
C772 CC, 50V, 100PF, 5%, 0603, C0G 150F-101J+P-AC
C773 CC, 50V, 100PF, 5%, 0603, C0G 150F-101J+P-AC
C774 CT, 16V, 10U, 20%, SMD 154D-106M+3-CF
C775 CT, 16V, 10U, 20%, SMD 154D-106M+3-CF
C776 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104K+P-AC
C777 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104K+P-AC
C778 CC, 50V, 0.1U, 5%, 0603 150F-104J+P-AC
C779 CC, 50V, 0.1U, 5%, 0603 150F-104J+P-AC
C780 CC, 50V, 0.1U, 5%, 0603 150F-104J+P-AC
C781 CC, 50V, 0.1U, 5%, 0603 150F-104J+P-AC
C782 CC, 50V, 100PF, 5%, 0603, C0G 150F-101J+P-AC
C783 CC, 50V, 100PF, 5%, 0603, C0G 150F-101J+P-AC
C784 CC, 50V, 470PF, 5%, 0603, C0G 150F-471J+P-AC
C785 CC, 50V, 470PF, 5%, 0603, C0G 150F-471J+P-AC
Inductors
Reference
Designator
Description
V
endor Part
Number
Note
L402 FERRITE, BEAD, CHIP, SEBW201209U121MT,
0805
1808-0872+0

Bose FreeSpace IZA 2120-HZ Specifications

General

Maximum current	5 A
AC input voltage	230 V
AC input frequency	50 Hz
Amplifier class	D
Frequency range	55 - 20000 Hz
Audio output channels	2.0 channels
Peak power per channel	- W
Total Harmonic Distortion (THD)	0.3 %
Purpose	Performance/stage
Equalizer	Yes
Product color	Silver
Volume control	Rotary
Connectivity technology	Wired
Line inputs (RCA)	2
Speakers connectivity type	RCA
Package weight	5400 g

Weight and Dimensions

Depth	324 mm
Width	483 mm
Height	44 mm
Weight	4100 g
