Bose FreeSpace IZA 2120-HZ Service Manual

73
Capacitors (continued)
ELECTRICAL PART LIST
Reference
Designator
Description
V
endor Part
Number
Note
C266 CC, 50V, 0.1uF, 10%, 0805, 1.2X2.0 150F-104KBD
C267 CE, 25V, 470U, 20%, RLT, 10X16, 105C, RX,
NOVER
157E-477MS5TU
C268 CE, 25V, 470U, 20%, RLT, 10X16, 105C, RX,
NOVER
157E-477MS5TU
C269 CE, 25V, 470U, 20%, RLT, 10X16, 105C, RX,
NOVER
157E-477MS5TU
C270 CE, 25V, 470U, 20%, RLT, 10X16, 105C, RX,
NOVER
157E-477MS5TU
C271 CE, 35V, 100U, 20%, RLT, 6.3X11, 105C, LOW,
ESR
157Q-107MLUTR
C273 CC, 50V, 0.47U, 10%, 0805, 1.25X2, X7R 150F-474KBD
C274 CC, 500V, 0.022U, 10%, 1206 150L-223KCF
C275 CC, 50V, 100PF, 5%, 0603, C0G 150F-101JAC
C276 CC, 50V, 100PF, 5%, 0603, C0G 150F-101JAC
C277 CC, 50V, 100PF, 5%, 0603, C0G 150F-101JAC
C278 CC, 50V, 100PF, 5%, 0603, C0G 150F-101JAC
C279 CC, 50V, 100PF, 5%, 0603, C0G 150F-101JAC
C280 CE, 35V, 47U, 20%, RLT, 6.3X11, 105C, RX,
NOVER
157Q-476MLUTU
C282 CM, 630V, 0.1U, 10%, RB, 17X16X10, P15,
FARATRONIC
153M-104K654
C283 CM, 630V, 0.1U, 10%, RB, 17X16X10, P15,
FARATRONIC
153M-104K654
C284 CC, 50V, 1U, 10%, 0805 150F-105KBD
C285 CC, 50V, 0.01U, 5%, 0603 150F-103JAC
C287 CC, 250V, 0.1U, 10%, X7R, 1206, 1.6X3.2 150R-104KCF
C288 CC, 250V, 0.1U, 10%, X7R, 1206, 1.6X3.2 150R-104KCF
C289 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C290 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C293 CC, 50V, 0.01U, 5%, 0603 150F-103JAC
C294 CC, 50V, 0.01U, 5%, 0603 150F-103JAC
C295 CC, 50V, 0.01U, 5%, 0603 150F-103JAC
C296 CE, 16V, 470U, 20%, RLT, 10X12.5, 105C, LOW
ESR
157D-477MSXTR
C297 CE, 16V, 470U, 20%, RLT, 10X12.5, 105C, LOW
ESR
157D-477MSXTR
C298 CC, 50V, 0.1uF, 10%, 0805, 1.2X2.0 150F-104KBD
C299 CC, 50V, 0.1uF, 10%, 0805, 1.2X2.0 150F-104KBD
C303 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C306 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C307 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C308 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C310 CER2, 1206, X7R, 50V, 100N, PM10, R 150F-104KCF
C311 CER2, 1206, X7R, 50V, 100N, PM10, R 150F-104KCF
C312 CC, 630V, 0.1U, 10%, 1812, X7R 150M-104KHF
C313 CC, 50V, 0.47U, 10%, 0805, 1.25X2, X7R 150F-474KBD
C314 CC, 500V, 0.022U, 10%, 1206 150L-223KCF
C315 CC, 630V, 0.1U, 10%, 1812, X7R 150M-104KHF
FreeSpace
®
IZA 2120-LZ and ZA 2120-LZ SMPS PCB Assembly

Bose FreeSpace IZA 2120-HZ Specifications

General

Maximum current	5 A
AC input voltage	230 V
AC input frequency	50 Hz
Amplifier class	D
Frequency range	55 - 20000 Hz
Audio output channels	2.0 channels
Peak power per channel	- W
Total Harmonic Distortion (THD)	0.3 %
Purpose	Performance/stage
Equalizer	Yes
Product color	Silver
Volume control	Rotary
Connectivity technology	Wired
Line inputs (RCA)	2
Speakers connectivity type	RCA
Package weight	5400 g

Weight and Dimensions

Depth	324 mm
Width	483 mm
Height	44 mm
Weight	4100 g
