86
ELECTRICAL PART LIST
FreeSpace
®
IZA 2120-LZ DSP PCB Assembly
Capacitors (continued)
Reference
Designator
Description
V
endor Part
Number
Note
C546 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C547 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C548 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C549 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C550 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C551 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C552 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C553 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C554 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C555 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C556 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C557 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C558 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C559 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C560 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C561 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C562 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C563 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C564 CE, 25V, 10U, 20%, 5.3X5.4, SMD,
UWX1E100MCR1GB, NCC
157E-106MJJC
C565 CE, 35V, 47U, 20%, SM, 6.6X5.7, LOW ESR,
LELON
157Q-476MMKR5
Reference
Designator
Description
V
endor Part
Number
Note
L400 INDUCTOR, 22UH, 20%, 8.1X8, B1000AS-
220M=P3, SMD, TOKO
1803-0103
L401 FERRITE, BEAD, CHIP, SEBW201209U121MT,
0805
1808-0872
L404 FERRITE, BEAD, CHIP, SEBW201209U121MT,
0805
1808-0872
L405 FERRITE, BEAD, CHIP, SEBW201209U121MT,
0805
1808-0872
L407 FERRITE, BEAD, CHIP, SEBW201209U121MT,
0805
1808-0872
L408 FERRITE, BEAD, CHIP, SEBW201209U121MT,
0805
1808-0872
L409 FERRITE, CHIP, 0603, BLM18AG102SN1D,
MURATA
1808-0878
L410 FERRITE, CHIP, 0603, BLM18AG102SN1D,
MURATA
1808-0878
L411 FERRITE, CHIP, 0603, BLM18AG102SN1D,
MURATA
1808-0878
L412 FERRITE, CHIP, 0603, BLM18AG102SN1D,
MURATA
1808-0878
L415 FERRITE, CHIP, 0603, BLM18AG102SN1D,
MURATA
1808-0878
L416 FERRITE, CHIP, 0603, BLM18AG102SN1D,
MURATA
1808-0878
Inductors
