Bose FreeSpace IZA 2120-HZ Service Manual

93
ELECTRICAL PART LIST
FreeSpace
®
IZA 2120-LZ Rear Panel PCB Assembly
Resistors (continued)
Reference
Designator
Description
V
endor Part
Number
Note
R888 RMG, 1/16W, 0R, 1%, 0603 4723-000A+P
R889 RMG, 1/16W, 0R, 1%, 0603 4723-000A+P
R892 RMG, 1/16W, 1.5K, 1%, 0603 4723-152A+P-R
R893 RMG, 1/16W, 2.7K, 1%, 0603/1608 4723-272A+P
R894 RMG, 1/16W, 1K, 1%, 0603/1608 4723-102A+P
R895 RMG, 1/16W, 5.1K, 1%, 0603/1608 4723-512A+P
Capacitors
Reference
Designator
Description
V
endor Part
Number
Note
C700 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104K+P-AC
C701 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104K+P-AC
C702 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104K+P-AC
C709 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104K+P-AC
C710 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104K+P-AC
C711 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104K+P-AC
C712 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104K+P-AC
C713 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104K+P-AC
C714 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104K+P-AC
C717 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104K+P-AC
C718 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104K+P-AC
C721 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104K+P-AC
C722 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104K+P-AC
C723 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104K+P-AC
C724 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104K+P-AC
C725 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104K+P-AC
C726 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104K+P-AC
C727 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104K+P-AC
C728 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104K+P-AC
C729 CC, 50V, 1000P, 5%, 0603, X7R 150F-102J+P-AC
C730 CC, 50V, 1000P, 5%, 0603, X7R 150F-102J+P-AC
C735 CC, 50V, 1000P, 5%, 0603, X7R 150F-102J+P-AC
C739 CC, 50V, 1000P, 5%, 0603, X7R 150F-102J+P-AC
C741 CC, 50V, 100PF, 5%, 0603, C0G 150F-101J+P-AC
C743 CC, 50V, 100PF, 5%, 0603, C0G 150F-101J+P-AC
C746 CC, 50V, 1000P, 5%, 0603, X7R 150F-102J+P-AC
C747 CC, 50V, 1000P, 5%, 0603, X7R 150F-102J+P-AC
C749 CC, 50V, 1000P, 5%, 0603, X7R 150F-102J+P-AC
C750 CC, 50V, 1000P, 5%, 0603, X7R 150F-102J+P-AC
C755 CC, 50V, 100PF, 5%, 0603, C0G 150F-101J+P-AC
C757 CC, 50V, 100PF, 5%, 0603, C0G 150F-101J+P-AC
C760 CC, 50V, 1000P, 5%, 0603, X7R 150F-102J+P-AC
C761 CC, 50V, 1000P, 5%, 0603, X7R 150F-102J+P-AC
C762 CC, 50V, 1000P, 5%, 0603, X7R 150F-102J+P-AC
C765 CC, 50V, 1000P, 5%, 0603, X7R 150F-102J+P-AC
C767 CC, 50V, 1000P, 5%, 0603, X7R 150F-102J+P-AC
C768 CC, 50V, 1000p, 5%, 0805, 1.25X2.0, MURATA 150F-102J+J-BDM
C769 CC, 50V, 1000p, 5%, 0805, 1.25X2.0, MURATA 150F-102J+J-BDM
C771 CC, 50V, 1000P, 5%, 0603, X7R 150F-102J+P-AC
C772 CC, 50V, 22P, 5%, 0603, C0G 150F-220J+P-AC
C773 CC, 50V, 22P, 5%, 0603, C0G 150F-220J+P-AC
C774 CC, 50V, 0.01uF, 10%, 0603, X7R 150F-103K+P-AC

Bose FreeSpace IZA 2120-HZ Specifications

General

Maximum current	5 A
AC input voltage	230 V
AC input frequency	50 Hz
Amplifier class	D
Frequency range	55 - 20000 Hz
Audio output channels	2.0 channels
Peak power per channel	- W
Total Harmonic Distortion (THD)	0.3 %
Purpose	Performance/stage
Equalizer	Yes
Product color	Silver
Volume control	Rotary
Connectivity technology	Wired
Line inputs (RCA)	2
Speakers connectivity type	RCA
Package weight	5400 g

Weight and Dimensions

Depth	324 mm
Width	483 mm
Height	44 mm
Weight	4100 g
