Bose FreeSpace IZA 2120-HZ - Page 95

95
ELECTRICAL PART LIST
FreeSpace
®
IZA 2120-LZ Rear Panel PCB Assembly
Capacitors (continued)
Reference
Designator
Description
V
endor Part
Number
Note
C866 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104K+P-AC
C867 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104K+P-AC
C868 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104K+P-AC
C869 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104K+P-AC
C870 CC, 50V, 0.01U, 5%, 0603 150F-103J+P-AC
Diodes
Reference
Designator
Description
V
endor Part
Number
Note
D704 DIODE, BAV99, SOT23, PHILIPS 4840-8970+3
D705 DIODE, BAV99, SOT23, PHILIPS 4840-8970+3
D706 DIODE, BAV99, SOT23, PHILIPS 4840-8970+3
D707 DIODE, BAV99, SOT23, PHILIPS 4840-8970+3
D710 DIODE, BAV99, SOT23, PHILIPS 4840-8970+3
D711 DIODE, BAV99, SOT23, PHILIPS 4840-8970+3
D712 DIODE, BAV99, SOT23, PHILIPS 4840-8970+3
D713 DIODE, BAV99, SOT23, PHILIPS 4840-8970+3
D714 DIODE, BAV99, SOT23, PHILIPS 4840-8970+3
D715 DIODE, BAV99, SOT23, PHILIPS 4840-8970+3
D716 DOUBLE, DIODE, BAT54S, SOT-23, SCHOTTKY,
SMD
480T-54S0+3
Z700 DZ, 1/2W, 6.2VB, SMD, LL-34, ROHM(RLZTE-
116.2B)
4837-6V21+3
Z701 DZ, 1/2W, 6.2VB, SMD, LL-34, ROHM(RLZTE-
116.2B)
4837-6V21+3
Transistors
Reference
Designator
Description
V
endor Part
Number
Note
Q708 TR, MMBT4403LT1G, SMD 4854-4030+3
Q709 TR, MMBT4403LT1G, SMD 4854-4030+3
Q710 TR, MMBT4403LT1G, SMD 4854-4030+3
Q711 TR, MMBT4403LT1G, SMD 4854-4030+3
Q712 TR, MMBT4403LT1G, SMD 4854-4030+3
Q713 TR, MMBT4403LT1G, SMD 4854-4030+3
Q714 TR, MMBT4403LT1G, SMD 4854-4030+3
Q715 TR, MMBT4403LT1G, SMD 4854-4030+3
Q718 TR, NPN, MMBT4401, SOT-23, HFE:20-300, SM 4854-4010+3
Q719 TR, NPN, MMBT4401, SOT-23, HFE:20-300, SM 4854-4010+3
Q720 TR, NPN, MMBT4401, SOT-23, HFE:20-300, SM 4854-4010+3
Reference
Designator
Description
V
endor Part
Number
Note
U701 IC, NJM2068M-#ZZZB, DUAL, OP, AMP 3130-6890+0
U702 IC, OP, AMP, SWITCH, NJM2120M, SOIC8, JRC 3132-3711+0
U703 IC, OP, AMP, SWITCH, NJM2120M, SOIC8, JRC 3132-3711+0
U706 IC, TL072CDR, DUAL J-FET, INPUT, OP-AMP,
(SMD)
3130-8020+0
U708 IC, TL072CDR, DUAL J-FET, INPUT, OP-AMP,
(SMD)
3130-8020+0
U709 IC, TL072CDR, DUAL J-FET, INPUT, OP-AMP,
(SMD)
3130-8020+0
Integrated Circuits
