ELECTRICAL PART LIST
Capacitors
FreeSpace
®
IZA 2120-HZ and ZA 2120-HZ Amplifier PCB Assembly
Reference
Designator
Description
V
endor Part
Number
Note
C1 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C2 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C3 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C4 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C5 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C6 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C7 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C8 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C9 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C10 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C11 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C12 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C13 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C14 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C15 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C16 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C25 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C26 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C27 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C28 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C29 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C30 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C31 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C32 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C33 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C34 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C35 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C36 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C37 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C38 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C40 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C41 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C42 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C43 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C44 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C45 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C46 CC, 25V, 10U, 10%, 1206, 3.2X1.6, X5R 150E-106KCF
C47 CC, 25V, 10U, 10%, 1206, 3.2X1.6, X5R 150E-106KCF
C50 CC, 25V, 10U, 10%, 1206, 3.2X1.6, X5R 150E-106KCF
C51 CC, 25V, 10U, 10%, 1206, 3.2X1.6, X5R 150E-106KCF
C52 CC, 25V, 10U, 10%, 1206, 3.2X1.6, X5R 150E-106KCF
C53 CC, 25V, 10U, 10%, 1206, 3.2X1.6, X5R 150E-106KCF
C54 CC, 25V, 10U, 10%, 1206, 3.2X1.6, X5R 150E-106KCF
C55 CC, 25V, 10U, 10%, 1206, 3.2X1.6, X5R 150E-106KCF
C57 CC, 50V, 1U, 10%, 1206, X7R 150F-105KCFM
C58 CC, 50V, 1U, 10%, 1206, X7R 150F-105KCFM
C59 CC, 50V, 1U, 10%, 1206, X7R 150F-105KCFM
C61 CC, 50V, 1U, 10%, 1206, X7R 150F-105KCFM
C64 CE, 16V, 100U, 20%, RLT, 6.3X11, 105C, RX,
NOVER
157D-107MLUTU
C65 CE, 16V, 100U, 20%, RLT, 6.3X11, 105C, RX,
NOVER
157D-107MLUTU
