ELECTRICAL PART LIST
Capacitors (continued)
FreeSpace
®
IZA 2120-HZ and ZA 2120-HZ Amplifier PCB Assembly
Reference
Designator
Description
V
endor Part
Number
Note
C66 CM, 400V, 0.1U, 5%, RB, 17.5X11X5 153T-104J7U
C67 CM, 400V, 0.1U, 5%, RB, 17.5X11X5 153T-104J7U
C68 CM, 400V, 0.1U, 5%, RB, 17.5X11X5 153T-104J7U
C69 CM, 400V, 0.1U, 5%, RB, 17.5X11X5 153T-104J7U
C74 CE, 16V, 10U, 20%, RLT, 5X11 157D-106MIU
C75 CE, 16V, 10U, 20%, RLT, 5X11 157D-106MIU
C76 CE, 6.3V, 330U, 20%, RLT, 8X7 157B-337MOM
C77 CE, 6.3V, 330U, 20%, RLT, 8X7 157B-337MOM
C78 CC, 630V, 1000P, 10%, 1206 150M-102KCF
C79 CC, 630V, 1000P, 10%, 1206 150M-102KCF
C80 CC, 630V, 1000P, 10%, 1206 150M-102KCF
C81 CC, 630V, 1000P, 10%, 1206 150M-102KCF
C82 CC, 630V, 1000P, 10%, 1206 150M-102KCF
C83 CC, 630V, 1000P, 10%, 1206 150M-102KCF
C84 CC, 630V, 1000P, 10%, 1206 150M-102KCF
C85 CC, 630V, 1000P, 10%, 1206 150M-102KCF
C86 CC, 630V, 1000P, 10%, 1206 150M-102KCF
C87 CC, 630V, 1000P, 10%, 1206 150M-102KCF
C88 CC, 250V, 0.1U, 10%, X7R 150R-104KCF
C89 CC, 250V, 0.1U, 10%, X7R 150R-104KCF
C90 CC, 250V, 0.1U, 10%, X7R 150R-104KCF
C91 CC, 250V, 0.1U, 10%, X7R 150R-104KCF
C92 CC, 250V, 0.1U, 10%, X7R 150R-104KCF
C93 CC, 250V, 0.1U, 10%, X7R 150R-104KCF
C94 CC, 250V, 0.1U, 10%, X7R 150R-104KCF
C95 CC, 250V, 0.1U, 10%, X7R 150R-104KCF
C96 CC, 250V, 0.1U, 10%, X7R 150R-104KCF
C97 CC, 250V, 0.1U, 10%, X7R 150R-104KCF
C98 CC, 250V, 0.1U, 10%, X7R 150R-104KCF
C99 CC, 250V, 0.1U, 10%, X7R 150R-104KCF
C100 CC, 50V, 220PF, 5%, 0603, C0G 150F-221JAC
C101 CC, 50V, 220PF, 5%, 0603, C0G 150F-221JAC
C102 CC, 50V, 220PF, 5%, 0603, C0G 150F-221JAC
C103 CC, 50V, 220PF, 5%, 0603, C0G 150F-221JAC
C104 CC, 50V, 75PF, 5%, 0603, C0G 150F-750JAC
C105 CC, 50V, 100PF, 5%, 0603, C0G 150F-101JAC
C106 CC, 50V, 75PF, 5%, 0603, C0G 150F-750JAC
C107 CC, 50V, 100PF, 5%, 0603, C0G 150F-101JAC
C108 CC, 50V, 100PF, 5%, 0603, C0G 150F-101JAC
C109 CC, 50V, 100PF, 5%, 0603, C0G 150F-101JAC
C110 CE, 250V, 47U, 20%, RLT, 12.5X25,
UVR2E470MHA, NCC
157R-476MX&C
C111 CE, 250V, 47U, 20%, RLT, 12.5X25,
UVR2E470MHA, NCC
157R-476MX&C
C112 CE, 250V, 47U, 20%, RLT, 12.5X25,
UVR2E470MHA, NCC
157R-476MX&C
C113 CE, 250V, 47U, 20%, RLT, 12.5X25,
UVR2E470MHA, NCC
157R-476MX&C
C114 CC, 630V, 1000P, 10%, 1206 150M-102KCF
C115 CC, 630V, 1000P, 10%, 1206 150M-102KCF
C116 CC, 630V, 1000P, 10%, 1206 150M-102KCF
C117 CC, 630V, 1000P, 10%, 1206 150M-102KCF
