Bose FreeSpace IZA 2120-LZ - Page 74

74
Inductors
ELECTRICAL PART LIST
FreeSpace
®
IZA 2120-LZ and ZA 2120-LZ SMPS PCB Assembly
Reference
Designator
Description
V
endor Part
Number
Note
L202 FERRITE BEAD, CHIP, SEBW201209U121MT,
0805
1808-0872
L203 FERRITE BEAD, CHIP, SEBW201209U121MT,
0805
1808-0872
L204 FERRITE BEAD, CHIP, SEBW201209U121MT,
0805
1808-0872
L205 FERRITE BEAD, CHIP, SEBW201209U121MT,
0805
1808-0872
L208 FERRITE BEAD, CHIP, SEBW201209U121MT,
0805
1808-0872
L211 FERRITE BEAD, CHIP, SEBW201209U121MT,
0805
1808-0872
L212 FERRITE BEAD, INDUCTOR, BL01RN1A1F1J 1808-0680
L213 FERRITE BEAD, INDUCTOR, BL01RN1A1F1J 1808-0680
Diodes
Reference
Designator
Description
V
endor Part
Number
Note
BR200 DIODE, BRIDGE, 600V, 8A, GBU8J, RL 4840-9211 3
D200 DIODE, IN5408-B, 3A, 1000V 4805-4080
D201 DIODE, SCHOTTKY, SK16, DO-214AA, 60V, 1A,
SMD, PANJIT
480S-K160
D202 DIODE, SCHOTTKY, 650V, 6A, IDH06G65C5, TO-
220, RL
4806-5C50
D203 DIODE, SCHOTTKY, 200V, 20A, MBR20200FCT,
ITO-220AB, RL
4800-FCT0
D204 DIODE, SCHOTTKY, 200V, 20A, MBR20200FCT,
ITO-220AB, RL
4800-FCT0
D205 DIODE, SCHOTTKY, 200V, 20A, MBR20200FCT,
ITO-220AB, RL
4800-FCT0
D206 DIODE, SCHOTTKY, 200V, 20A, MBR20200FCT,
ITO-220AB, RL
4800-FCT0
D207 DIODE, SCHOTTKY, 40V, 2A, SK24, SMB, SM,
PANJIT
480S-K240
D208 DIODE, BAV99, SOT23, PHILIPS 4840-8970
D209 DIODE, ULTRA, 600V, 1A, MURS, 160T3, SMB,
CASE403A, SM
4806-0T30
D210 DIODE, ULTRA, 600V, 1A, MURS, 160T3, SMB,
CASE403A, SM
4806-0T30
D211 DIODE, ULTRA, 600V, 1A, MURS, 160T3, SMB,
CASE403A, SM
4806-0T30
D212 DIODE, ULTRA, 600V, 1A, MURS, 160T3, SMB,
CASE403A, SM
4806-0T30
D213 DIODE, SUPPRESSOR, 200V, P6KE200A, AT 4802-00A0
D214 DIODE, 600V, 1A, 75NS, US1J, SOD124 480U-S1J0
D216 DIODE, FAST, 75V, 0.5A, BAS316, SOD323, SM 480S-3160
D217 DIODE, FAST, 75V, 0.5A, BAS316, SOD323, SM 480S-3160
D218 DIODE, FAST, 75V, 0.5A, BAS316, SOD323, SM 480S-3160
D219 DIODE, FAST, 75V, 0.5A, BAS316, SOD323, SM 480S-3160
D223 DIODE, RECT, 200V, 2A, ER2D, SMB/DO-214AA,
SM
480E-R2D0
