Bose FreeSpace IZA 2120-LZ - Page 75

75
ELECTRICAL PART LIST
FreeSpace
®
IZA 2120-LZ and ZA 2120-LZ SMPS PCB Assembly
Diodes (continued)
Transistors
Reference
Designator
Description
V
endor Part
Number
Note
Q200 MOSFET, N-CH, 600V, 12A, FQPF12N60C, TO-
220F, RL
490N-60C0
Q201 MOSFET, N-CH, 600V, 12A, FQPF12N60C, TO-
220F, RL
490N-60C0
Q205 TR, NPN, BCP56-10, SOT223 485C-P560
Q206 MOSFET, N-CH, 800V, TK6A80E, 6A, TO-220SIS,
RL
490A-80E0
Q207 TR, 3904, HFE, 100-300, SM 4860-0640
Q208 TR, 3904, HFE, 100-300, SM 4860-0640
Q209 MOSFET, N-CH, 600V, 10A, STP11NM60ND, TO-
220, RL
4906-0ND0
Q211 TR, NPN, BCP56-10, SOT223 485C-P560
Q212 MOSFET, N-CH, 60V, 115MA, 2N7002, SOT-23,
SM
4907-0020
Integrated Circuits
Reference
Designator
Description
V
endor Part
Number
Note
U200 IC, DRIVER, NCP5181DR2G, SOIC-8 3132-8471
U201 IC, LM19, THERMAL SENSOR, TO-92, NS 3132-2581
U202 IC, LM339, SMD, COMPARATOR 3132-1250
U203 PHOTOCOUPLER, EL817S1, S1 4818-17S1
U204 PHOTOCOUPLER, EL817S1, S1 4818-17S1 3
U205 PHOTOCOUPLER, EL817S1, S1 4818-17S1 3
U206 IC, REGULATOR, 5V, LM78L05ACM, SO-8 3131-3390
U207 IC, PFC, CONTROLLER, IR1155S, SO8 3132-9880
U208 IC, POWER, NCP1271, SO-8, ONSEMI 3132-806111
U209 IC, LLC, SMPS, UCC25600, SOIC-8 3132-8371
U210 IC, REGULATOR, TL432BIDBZR, SOT-23-3, TI 3132-769116
U211 IC, REGULATOR, TL432BIDBZR, SOT-23-3, TI 3132-769116
U212 PHOTOCOUPLER, EL817S1, S1 4818-17S1 3
U213 IC, NJM78M05DL1A-#ZZZB, REGULATOR 3132-2101
Reference
Designator
Description
V
endor Part
Number
Note
D224 DIODE, RECT, 200V, 2A, ER2D, SMB/DO-214AA,
SM
480E-R2D0
D226 RECTIFIER, ES1D, 200V, 1.1A, SMD 4840-9190
D232 DIODE, SCHOTTKY, SK16, DO-214AA, 60V, 1A,
SMD, PANJIT
480S-K160
DZ202 DZ, 1/2W, 15V, 5%, SOD-123C, MMSZ5245BT1G 4837-15V9
Z200 DZ, 1/2W, 15V, 5%, SOD-123C, MMSZ5245BT1G 4837-15V9
Z201 DZ, 1/2W, 18V, 5%, SOD-123C, MMSZ5248BT1G 4837-18V9
Z203 DZ, 1/2W, 18V, 5%, SOD-123C, MMSZ5248BT1G 4837-18V9
