Bose PowerShare PS602 Service Manual

59
Capacitors (continued)
ELECTRICAL PART LIST
Rear Panel PCB Assembly, PS604
Diodes
Reference
Designator
Description
V
endor Part
Number
Note
D704 DIODE, BAV99, SOT23, PHILIPS 4840-8970
D705 DIODE, BAV99, SOT23, PHILIPS 4840-8970
D706 DIODE, BAV99, SOT23, PHILIPS 4840-8970
D707 DIODE, BAV99, SOT23, PHILIPS 4840-8970
D710 DIODE, BAV99, SOT23, PHILIPS 4840-8970
D711 DIODE, BAV99, SOT23, PHILIPS 4840-8970
D712 DIODE, BAV99, SOT23, PHILIPS 4840-8970
D713 DIODE, BAV99, SOT23, PHILIPS 4840-8970
D717 DIODE, BAV99, SOT23, PHILIPS 4840-8970
Z700 DZ, 1/2W, 6.2VB, SMD, LL-34, ROHM
(RLZTE-116.2B)
4837-6V21
Z701 DZ, 1/2W, 6.2VB, SMD, LL-34, ROHM
(RLZTE-116.2B)
4837-6V21
Z702 DZ, 1/2W, 6.2VB, SMD, LL-34, ROHM
(RLZTE-116.2B)
4837-6V21
Z703 DZ, 1/2W, 6.2VB, SMD, LL-34, ROHM
(RLZTE-116.2B)
4837-6V21
Z704 DZ, 1/2W, 6.2VB, SMD, LL-34, ROHM
(RLZTE-116.2B)
4837-6V21
Integrated Circuits
Reference
Designator
Description
V
endor Part
Number
Note
U705 IC, NJM2068M-#ZZZB, DUAL, OP, AMP 3130-6890
U706 IC, NJM2068M-#ZZZB, DUAL, OP, AMP 3130-6890
U707 IC, NJM2068M-#ZZZB, DUAL, OP, AMP 3130-6890
U708 IC, NJM2068M-#ZZZB, DUAL, OP, AMP 3130-6890
U709 IC, NJM2068M-#ZZZB, DUAL, OP, AMP 3130-6890
U711 IC, 16-CH, DEMULTIPLEXER, 74HC4067M96, SO24,
TEXAS
3132-3021
U712 IC, 8BIT, SHIFT, REGISTER, 74HC166, SO-16 3132-3281
U713 IC, 8BIT, SHIFT, REGISTER, 74HC166, SO-16 3132-3281
U714 IC, NJM2068M-#ZZZB, DUAL, OP, AMP 3130-6890
U715 IC, ANALOG-SW, DG211BDY-E3, SOIC-16 3133-0661
Reference
Designator
Description
V
endor Part
Number
Note
C892 CC, 50V, 0.01uF, 10%, 0603, X7R 150F-103KAC
C893 CC, 50V, 0.01uF, 10%, 0603, X7R 150F-103KAC
C894 CC, 50V, 0.01uF, 10%, 0603, X7R 150F-103KAC
C895 CC, 50V, 0.01uF, 10%, 0603, X7R 150F-103KAC
C896 CC, 50V, 0.01uF, 10%, 0603, X7R 150F-103KAC
C897 CC, 50V, 0.01uF, 10%, 0603, X7R 150F-103KAC
