Bose PowerShare PS602

60
Miscellaneous
ELECTRICAL PART LIST
Rear Panel PCB Assembly, PS604
Reference
Designator
Description
V
endor Part
Number
Note
J701 SOCKET, M, 2P, P5, 300V, 15A, BLACK 2113-3361
J711B CONNECTOR, PIN, HEADER, 4P, P2.54, ST, F 2101-3294
J717 CONN, HEADER, 8P, P2.54, DIP, ST, M, L=8.54 2101-3408
J718 CONN, HEADER, 8P, P2.54, DIP, ST, M, L=8.54 2101-3408
J724 CONN, FFC, 20P, P0.5, SMT, ST, F 2101-3376
J725 CONN, FFC, 20P, P0.5, SMT, ST, F 2101-3376
J728 DIN, SOCKET, M, 12P, P5, 300V, 15A, 60, GREEN 2113-3458
J740 CONN, HEADER, 5P, P2.54, DIP, ST, M, L=11.08 2101-3409
J741 CONN, HEADER, 5P, P2.54, DIP, ST, M, L=11.08 2101-3409
J742 CONN, HEADER, 5P, P2.54, DIP, ST, M, L=11.08 2101-3409
J743 CONN, HEADER, 5P, P2.54, DIP, ST, M, L=11.08 2101-3409
J760B CONN, PIN, HEADER, 4P, P2.54, ST, F 2101-3294
J761B CONN, PIN, HEADER, 4P, P2.54, ST, F 2101-3294
VR705 VR, ROT, 20BKX1, 20%, V, L=15, 18TEETH, CTR 4751-226E
VR706 VR, ROT, 20BKX1, 20%, V, L=15, 18TEETH, CTR 4751-226E
VR707 VR, ROT, 20BKX1, 20%, V, L=15, 18TEETH, CTR 4751-226E
VR708 VR, ROT, 20BKX1, 20%, V, L=15, 18TEETH, CTR 4751-226E
