Main PCB Electrical Part List
Reference Designator Description Vendor Part Number Note
R307, R328, R352
CHIP, 56K OHM, 100PPM, +-
1%, 0402, WALS, L
T502560201399 2
R308, R316
CHIP, 47K OHM, 100PPM, +-
1%, 0603, WALS, L
T502470202399 2
R311
CHIP, 1K OHM 100PPM, +-
1%, 0603, WALS, L, WR06X-
1001FTL
T502100102399 2
R321
CHIP, 1.37K OHM, 100PPM,
+- 1%, 0603, WALS, L, WR06X-
1371FTL
T502137102399 2
R322, R323, R326, R377
CHIP, 2K OHM, 100PPM, +-
1%, 0603, WALS, L
T502200102399 2
R343, R348, R339
CHIP, 330K OHM, 100PPM, +-
1%, 0603, WALS, L
T502330302399 2
R345
CHIP, 560K OHM, 100PPM, +-
1%, 0402, WALS, L
T502560301399 2
R351
CHIP, 51K OHM, 100PPM, +-
1%, 0603, WALS, L
T502510202399 2
R356
CHIP, 3K OHM, 100PPM, +-
1%, 0603, WALS, L
T502300102399 2
R495
CHIP, 220 OHM, 100PPM, +-
1%, 0402, WALS, L
T502220001399 2
R498
CHIP, 4.7M OHM, 100PPM, +-
1%, 0603, WALS, L
T502470402399 2
R499, R500
CHIP, 2.2K OHM, 100PPM, +-
1%, 1206, WALS, L
T502220104399 2
R501
CHIP, 1 OHM, 100PPM,
1%,1206, KOA, K,
SR732BTTD1R00F
T710600016600
2,3
R510, R511
CHIP, 24 OHM, 100PPM, +-
1%, 1206, WALS, L, WR12X-
24R0FTL
T502240A04399 2
R602, R194, R206, R218,
R238
CHIP, 0 OHM, 0603, WALS, L,
WR06X000PTL
T502000002009 2
R606
CHIP, 3.3K OHM, 100PPM, +-
1%, 0402, WALS, L
T502330101399 2
R610, R611
CHIP, 1M OHM, 100PPM, +-
1%, 0805, WALS, L
T502100403399 2
R620
CHIP, 10 OHM, 100PPM, +- 1%,
0402, WALS, L
T502100A01399 2
Resistors (continued)
