Bose S1 Pro Service Manual

14
Main PCB Electrical Part List
Reference Designator Description Vendor Part Number Note
C1,C3,C167,C176 CAP X7R 1.0uF 50V +-10% 0805
WALSIN L
T542031057508
2
C4, C7, C9, C11, C16, C37, C38,
C39, C41, C45, C48, C54, C57,
C61, C62, C67, C68, C69, C71,
C72, C73, C74, C75, C76, C77,
C78, C79, C80, C81, C86, C88,
C89, C90, C93, C94, C95, C96,
C97, C99, C100, C101, C102,
C103, C104, C123, C128, C135,
C143, C151, C161, C162, C197,
C199, C207, C209, C216, C234,
C237, C245, C273, C308, C505,
C585, C594, C595, C598, C63,
C87, C612, C613, C614, C615,
C616, C617, C677, C678
CAP, X7R, .10uF, 50V, +- 10%,
0402, WALSIN, L
T542011047508 2
C5 SP, CAP, 0.47uF, 100V, +- 5%,
C242A474J2S, K, C242A474J-
2SA201
T560000000530 2
C6, C33, C44, C49, C50, C53,
C56, C70, C84, C85, C91, C110,
C113, C122, C129, C136, C137,
C196, C198, C208, C215,
CAP, 10uF, 6.3V, +, -20%,
0603X5R, WALSIN, , L
T540000002118 2
C8, C10, C14, C28, C625, C626,
C501, C502, C514, C515, C517
CAP, X7R, .01uF, 50V,
+- 10%, 0402, WALSIN, L,
0402B103K500CT
T542011037508 2
C12, C13, C179, C190 CAP, X7R, .047uF, 50V, +- 10%,
0402, WALSIN, L
T542014737508 2
C15, C20, C124, C178, C232,
C282, C264
CAP, NPO, 100pF, 50V, +- 5%,
0603, WALSIN, L
T541021016508 2
C17, C31, C32, C144, C242,
C262, C266, C267
CAP, NPO, 100pF, 50V, +- 5%,
0402, WALSIN, L
T541011016508 2
C18, C36, C147, C270
CAP, NPO, 270pF, 50V,
+- 5%, 0603, WALSIN, L,
0603N271J500CT
T541022716508 2
C19, C30, C98, C115, C138,
C139, C148, C152, C241, C265
CAP, NPO, 470pF, 50V, +- 5%,
0402, WALSIN, L
T541014716508 2
C21, C157, C158, C160, C170,
C172, C213, C233, C240, C244,
C258, C268
CAP, X7R, .68uF, 25V, +- 10%,
1206, WALSIN, L
T542046847408 2
C23, C27, C175, C181, C184,
C185, C202, C206, C210, C224,
C235, C238, C239, C250, C253,
C257, C280, C285, C286, C350,
C610, C630, C631, C188, C516
CAP, X7R, .10uF, 50V, +- 10%,
0603, WALSIN, L
T542021047508 2
C24, C34, C35, C154, C155,
C168, C243, C255
CAP, NPO, 220pF, 50V, +- 5%,
0603, MURATA, L, GRM-
1885C1H221JA01D
T541022216505 2
C25, C261 CAP, NPO, 2700pF, 50V, +- 5%,
0603, WALSIN, L
T541022726508 2
Capacitors
