15
Main PCB Electrical Part List
C26, C40, C46, C51, C52, C58,
C60
CAP, X5R,10uF, 25V, +-0%, 0805,
WALSIN, L, 0805X106K250CT
T545031067408 2
C42, C65, C66, C105, C108,
C120, C156, C214
E, 100uF, 6.3V, +- 20%, 5X5.3M,
VEJ101M0J, K, VEJ101M-
0JTR-0505
T551101415010 2
C43, C131 CAP, X5R, 4.7uF, 50V, +- 10%,
0805, WALSIN, L
T545034757508 2
C46
CAP, X5R, 10UF, 50V, +-10%,
0805, WALSIN L
T545031067505
2
C47, C117, C119, C29 CAP, NPO, 22pF, 50V, - 5%, 0402,
WALSIN, L, 0402N220J500CT
T541012206508 2
C55 CAP, X7R, 150pF, 50V, +- 10%,
0603, WALSIN, L
T542021517508 2
C59 CAP, X7R, 5600pF, 16V, +- 10%,
0402, WALSIN, L
T542015627308 2
C64, C112, C114, C118, C126,
C127, C130, C142, C132, C145,
C146, C153
CAP, NPO, 680pF, 50V, +- 5%,
0402, WALSIN, L
T541016816508 2
C92, C116, C134, C150 CAP, X7R, 1800pF, 50V, +- 10%,
0603, WALSIN, L
T542021827508 2
C106, C173, C259, C281 CAP, NPO, 1000pF, 50V, +- 5%,
0603, WALSIN, L
T541021026508 2
C107, C247
E, 100uF, 25V, +- 20%,
6.3X7., VEJ101M1E, K, VE-
J101M1ETR-0607
T551101445020 2
C109, C227, C666 CAP, X7R, .10uF, 500V, +- 10%,
1210, KEMET, L
T542051047906 2
C111, C163, C165, C275 E, 220UF, 35V, +- 20%, 8*10.5,
LV221M035, K, LV221M-
035F105ETR
T551221452010 2
C121, C166, C222, C223
E 470uF, 35V +-20% 10*12.
VZH471M1V K
T551471455000 2
C125
CAP, NPO, 390pF, 50V,
+- 5%, 0603, WALSIN, L,
0603N391J500CT
T541023916508 2
C133, C141
E 1000uF, 16V +-20% 8X15MM
RXW102M1C K
T552102435010 2
C149, C226, C231, C284
E, 47uF, 16V, +- 20%,
5X5.4M, CK1C470M-, K, CK-
1C470M-CRD54
T551470434020 2
C164, C193, C503 CAP, NPO, 330pF, 50V, +- 5%,
0402, WALSIN, L
T541013316508 2
C171, C177, C189, C201 CAP, X7R, .01uF, 100V, +- 10%,
0805, WALSIN, L
T542031037608 2
C174, C278 CAP, NPO, 18pF, 50V, +- 5%,
0603, WALSIN, L
T541021806508 2
C180, C186, C187, C191, C22,
C140, C159, C169, C194, C269
E, 22uF, 16V, +- 20%,
4X5.4M, CK1C220M-, K, CK-
1C220M-CRC54
T551220434010 2
Capacitors (continued)
To Next Page
