Bose S1 PRO+ Service Manual

22
MAIN-I/O PCB PARTS LIST
Integrated Circuit
Reference Designator Description Material Number Note
EDG1 MODULE, RF, BLUETOOTH, BABY YODA 833933-0020
F1 PTC, RESETTABLE, 0.75A, 100ms 320968-0754
J1 CONN, FPC, 0.5mm C, 22P, 1R, R, SMT, RA,
Au
857203-0022
J11 CONN, PHONE JACK, 6.35mm, 3P, R, TH 873494-0010
J12A, J12B CONN, IO, XLR, 10P, R, TH, ST 870566-0010
J5 CONN, FPC, 0.5mm C, 24P, 1R, R, SMT, ST 870476-0024
J6 CONN, HDR, 2mm C, 6P, 1R, P, TH, ST, WHT 859609-0006
J7, J15 CONN, FPC, 0.5mm C, 10P, R, SMT, ST, ZIF 869518-0010
J8 CONN, HDR, 1.5mm C, 2P, 1R, P, SMT, ST,
BEIGE
847746-0020
J9, J14, J16 CLAMP, CABLE, COAX, 1.13mm DIAM 873491-0010
P1 CONN, IO, XLR, 3P, R, TH, ST 870675-0010
PJ1 CONN, IO, 3.5mm EAR PHONE JACK, TH,
31.1L
852736-0010
SW1 SWITCH, TACT, 15V, 20mA, 320GF 854394-0010
SW2 SWITCH, TACT, 12V, 50mA, 250gf 850862-0010
Y1 CRYSTAL, FUND, 2520, 10ppm, 10pF, 24MHz 800165-
24M000BB10

Bose S1 PRO+ Specifications

General

Type	Handheld Public Address (PA) system
Handle(s)	Yes
Product color	Black
Housing material	Aluminium, Polypropylene (PP)
Storage temperature (T-T)	-20 - 49 °C
Operating temperature (T-T)	0 - 45 °C
Bluetooth range	9 m
Bluetooth version	5.0
Connectivity technology	Wired & Wireless
6.35 mm (1⁄4-inch) input	2
Charging time	5 h
AC input voltage	100 - 240 V
Battery capacity	5500 mAh
Power source type	AC, Battery
AC input frequency	50/60 Hz
Battery life (max)	11 h
Number of mixer channels	3 channels
Speaker type	2-way
Number of speakers	-
Frequency range	- Hz
RMS rated power	- W

Weight and Dimensions

Depth	279.8 mm
Width	240 mm
Height	332.6 mm
Weight	6500 g
