Bose S1 PRO+ Service Manual

15
MAIN-I/O PCB PARTS LIST
Resistors
Reference Designator Description Material Number Note
R1, R325A, R325B, R336A,
R336B
RES, THICK FILM, 0402, 0.063W, 1%, 2K 801703-2001F
R10-R11, R16-R17,
R24-R26, R58, R64,
R66, R68, R73-R74,
R77-R79, R81, R84-R89,
R91-R92, R99-R100,
R102-R111, R120, R123,
R127-R133, R137-R138,
R140, R144-R145,
R147-R148, R150-R154,
R159, R161, R167-R172,
R181, R190-R193, R195,
R198, R200-R204, R392,
R397, R408, R446-R449,
R457-R459, R462,
R485-R490, R505-R506,
R580
RES, THICK FILM, 0402, 0.063W, 1%, 33 OHM 801703-33R0F
R113 RES, THICK FILM, 0402, 0.063W, 1%, 82K 801703-8202F
R118, R316A, R316B,
R346A, R346B
RES, THICK FILM, 0402, 0.063W, 1%, 3.3K 801703-3301F
R12 RES, THICK FILM, 0402, 0.063W, 1%, 49.9
OHM
801703-49R9F
R124, R126, R491-R492 RES, THICK FILM, 0402, 0.063W, 1%, 4.22K 801703-4221F
R13 RES, THICK FILM, 0402, 0.063W, 1%, 5.1
OHM
801704-5R10F
R14 RES, THICK FILM, 0402, 0.063W, 1%, 13.3K 801703-1332F
R143, R146 RES, THICK FILM, 0603, 0.1W, 1%, 75 OHM 801706-75R0F
R15, R57, R93-R94,
R112, R162-R165, R177,
R196, R205, R210, R249,
R284, R298, R301, R303,
R369, R375, R385, R388,
R429, R431, R451-R453,
R501-R502, R348A, R348B,
R356A, R356B
RES, THICK FILM, 0402, 0.063W, 1%, 100K 801703-1003F
R211, R280, R288, R299,
R307
RES, THICK FILM, 0402, 0.063W, 1%, 2.2K 801703-2201F
R212-R213 JUMPER, CHIP, 0805 806732-0805
R241-R242, R248, R282,
R286, R300, R305,
R444-R445, R450, R469,
R319A, R319B, R343A,
R343B
RES, THICK FILM, 0402, 0.063W, 1%, 4.7K 801703-4701F
R255, R267, R291, R311,
R313, R21A, R21B, R22A,
R22B
RES, THICK FILM, 0402, 0.063W, 1%, 1K 801703-1001F
R256, R270, R292, R312 RES, THICK FILM, 0402, 0.063W, 1%, 1.5K 801703-1501F
R27, R37-R38, R49 RES, THICK FILM, 0402, 0.063W, 1%, 9.1K 801703-9101F
R273, R287, R293, R306 RES, THICK FILM, 0603, 0.1W, 1%, 28K 801706-2802F

Bose S1 PRO+ Specifications

General

Type	Handheld Public Address (PA) system
Handle(s)	Yes
Product color	Black
Housing material	Aluminium, Polypropylene (PP)
Storage temperature (T-T)	-20 - 49 °C
Operating temperature (T-T)	0 - 45 °C
Bluetooth range	9 m
Bluetooth version	5.0
Connectivity technology	Wired & Wireless
6.35 mm (1⁄4-inch) input	2
Charging time	5 h
AC input voltage	100 - 240 V
Battery capacity	5500 mAh
Power source type	AC, Battery
AC input frequency	50/60 Hz
Battery life (max)	11 h
Number of mixer channels	3 channels
Speaker type	2-way
Number of speakers	-
Frequency range	- Hz
RMS rated power	- W

Weight and Dimensions

Depth	279.8 mm
Width	240 mm
Height	332.6 mm
Weight	6500 g
