Bose S1 PRO+ Service Manual

16
MAIN-I/O PCB PARTS LIST
Resistors (continued)
Reference Designator Description Material Number Note
R274, R281, R297, R308 RES, THICK FILM, 0805, 0.125W, 1%, 100
OHM
802354-1000F
R275, R289, R294, R309 RES, THICK FILM, 0603, 0.1W, 1%, 14K 801706-1402F
R276, R279, R439, R456 RES, THICK FILM, 0402, 0.063W, 1%, 20K 801703-2002F
R277, R283, R295, R302 RES, THICK FILM, 0402, 0.063W, 1%, 120K 801703-1203F
R28, R32, R43, R48 RES, THICK FILM, 0402, 0.063W, 1%, 5.1K 801703-5101F
R29, R33, R35-R36,
R39-R40, R44, R47, R220,
R224, R260, R264, R520,
R524
RES, THICK FILM, 0402, 0.063W, 1%, 470
OHM
801703-4700F
R290, R310 RES, THICK FILM, 0402, 0.063W, 1%, 2.4K
OHM
801703-2401F
R31, R46, R315A, R315B,
R320A, R320B, R340A,
R340B, R344A, R344B
RES, THICK FILM, 0402, 0.063W, 1%, 47 OHM 801703-47R0F
R314A, R314B, R324A,
R324B, R332A, R332B,
R347A, R347B
RES, THICK FILM, 0402, 0.063W, 1%, 2.7K 801703-2701F
R317A, R317B, R321A,
R321B, R341A, R341B,
R345A, R345B, R365A,
R365B
RES, THICK FILM, 0402, 0.063W, 1%, 1.8K 801703-1801F
R322A, R322B, R338A,
R338B
RES, THICK FILM, 0805, 0.125W, 1%, 20 OHM 802354-20R0F
R323A, R323B, R326A,
R326B, R337A, R337B,
R339A, R339B
RES, THICK FILM, 0402, 0.063W, 1%, 220
OHM
801703-2200F
R327A, R327B, R328A,
R328B, R334A, R334B,
R335A, R335B
RES, THICK FILM, 0402, 0.063W, 1%, 2.2
MEG
801703-2204F
R333A, R333B RES, THICK FILM, 0603, 0.1W, 1%, 2.1K 801706-2101F
R34, R41, R166, R197,
R418, R522, R552, R330A,
R330B
RES, THICK FILM, 0402, 0.063W, 1%, 47K 801703-4702F
R349A, R349B, R350A,
R350B, R351A, R351B,
R352A, R352B, R360A,
R360B
RES, THICK FILM, 0603, 0.1W, 1%, 1K 801706-1001F
R353A, R353B, R357A,
R357B
RES, THICK FILM, 0402, 0.063W, 1%, 470K 801703-4703F
R362A, R362B RES, THICK FILM, 0402, 0.063W, 1%, 56 OHM 801703-56R0F
R364A, R364B RES, THICK FILM, 0402, 0.063W, 1%, 390
OHM
801703-3900F
R370, R394 RES, THICK FILM, 0603, 0.1W, 1%, 511K 801706-5113F
R371 RES, THICK FILM, 0603, 0.1W, 1%, 453K 801706-4533F
R374 RES, THICK FILM, 0603, 0.1W, 1%, 105K 801706-1053F
R395 RES, THICK FILM, 0603, 0.1W, 1%, 150K 801706-1503F
R398 RES, THICK FILM, 0603, 0.1W, 1%, 6.2K 801706-6201F

Bose S1 PRO+ Specifications

General

Type	Handheld Public Address (PA) system
Handle(s)	Yes
Product color	Black
Housing material	Aluminium, Polypropylene (PP)
Storage temperature (T-T)	-20 - 49 °C
Operating temperature (T-T)	0 - 45 °C
Bluetooth range	9 m
Bluetooth version	5.0
Connectivity technology	Wired & Wireless
6.35 mm (1⁄4-inch) input	2
Charging time	5 h
AC input voltage	100 - 240 V
Battery capacity	5500 mAh
Power source type	AC, Battery
AC input frequency	50/60 Hz
Battery life (max)	11 h
Number of mixer channels	3 channels
Speaker type	2-way
Number of speakers	-
Frequency range	- Hz
RMS rated power	- W

Weight and Dimensions

Depth	279.8 mm
Width	240 mm
Height	332.6 mm
Weight	6500 g
