Bose S1 PRO+ Service Manual

17
MAIN-I/O PCB PARTS LIST
Resistors (continued)
Reference Designator Description Material Number Note
R4, R6, R9, R19, R23,
R83, R96-R97, R156-R157,
R160, R475-R477,
R479-R481
RES, THICK FILM, 0402, 0.063W, 1%, 120
OHM
801703-1200F
R402 RES, THICK FILM, 0603, 0.1W, 1%, 56K 801706-5602F
R403 RES, THICK FILM, 0603,0.1W, 1%, 3K 801706-3001F
R42, R142, R176, R222,
R226-R227, R232, R234,
R238-R240, R243-R244,
R372, R460, R470-R472
JUMPER, CHIP, 0603 806732-0603
R468 RES, THICK FILM, 0402, 0.063W, 1%, 12.7K 801703-1272F
R5, R7-R8, R18, R20, R30,
R45, R60, R62, R71, R95,
R98, R155, R158, R454,
R467, R473-R474, R363A,
R363B
RES, THICK FILM, 0402, 0.063W, 1%, 100
OHM
801703-1000F
R50, R52, R54, R69,
R76, R82, R101, R114,
R135, R199, R207-R209,
R373, R376, R381-R382,
R384, R400, R409,
R414, R420, R424,
R427-R428, R434-R435,
R438, R483, R498-R499,
R529, R533-R534, R559,
R563-R564, R577
RES, THICK FILM, 0402, 0.063W, 1%, 10K 801703-1002F
R516, R546 RES, THICK FILM, 0603, 0.1W, 1%, 100 OHM 801706-1000F
R53 RES, THICK FILM, 0402, 0.063W, 1%, 5.6K 801703-5601F
R55 RES, THICK FILM, 0603, 0.1W, 1%, 10 OHM 801707-10R0F
R59, R70, R75, R117,
R121-R122, R134, R136,
R178-R180, R182-R188,
R217-R219, R221,
R228-R230, R245, R247,
R251, R257-R259, R262,
R268-R269, R272,
R377-R378, R380, R383,
R386, R391, R404, R406,
R411-R413, R415-R416,
R425, R463-R466, R482,
R493-R497, R515, R517,
R519, R521, R527-R528,
R531
JUMPER, CHIP, 0402 806732-0402
