Bose S1 PRO+ Service Manual

18
MAIN-I/O PCB PARTS LIST
Capacitors
Reference Designator Description Material Number Note
C1, C112-C113,
C124-C125, C252-C253,
C257
CAP, X5R, 0805, 50V, 10%, 4.7uF, COMM 743447-475K1H
C10, C133 CAP, C0G, 0402, 50V, 5%, 680pF, COMM 766718-681J1H
C107, C218A, C218B CAP, C0G, 0402, 50V, 5%, 15pF, COMM 766718-150J1H
C11, C17, C19, C84,
C135-C136
CAP, X5R, 0402, 10V, 10%, 1uF, COMM 716994-105K1A
C114, C286 CAP, X5R, 0402, 25V, 10%, 1uF, COMM 716994-105K1E
C121-C122 CAP, C0G, 0402, 50V, 5%, 10pF, COMM 766718-100J1H
C13 CAP, X7R, 0603, 50V, 10%, 0.1uF, COMM 718875-104K1H
C149-C150, C163-C164,
C380-C381
CAP, X7R, 0402, 50V, 10%, 2200pF, COMM 718866-222K1H
C15 CAP, C0G, 0402, 50V, 5%, 330pF, COMM 766718-331J1H
C16, C57, C62, C111, C123,
C287
CAP, EL, SMT, 105C, 25V, 20%, 100uF, COMM 856752-101M1ECC
C172, C180, C187, C195,
C197, C250, C235A,
C235B, C236A, C236B,
C237A, C237B, C238A,
C238B
CAP, C0G, 0402, 50V, 5%, 100pF, COMM 766718-101J1H
C2, C6-C8, C22, C24,
C27, C33, C41, C51,
C55, C71-C75, C81,
C86-C87, C91, C93,
C100, C102, C106, C110,
C115, C117, C119-C120,
C126, C128, C134,
C137-C139, C141, C144,
C146, C152, C155-C156,
C158-C159, C161, C167,
C176, C184, C200-C206,
C244-C247, C249, C251,
C254, C256, C258, C260,
C262-C263, C285, C358,
C361, C363-C364, C366,
C370, C373, C378, C383,
C385-C387, C398, C408,
C410-C412, C229A, C229B,
C230A, C230B, C231A,
C231B, C232A, C232B,
C233A, C233B, C234A,
C234B, C239A, C239B,
C241A, C241B, C243A,
C243B
CAP, X7R, 0402, 50V, 10%, 0.1uF, COMM 718866-104K1H
C210A, C210B, C227A,
C227B
CAP, C0G, 0603, 50V, 5%, 2700pF, COMM 780788-272J1H
C211A, C211B, C225A,
C225B
CAP, EL, SMT, 105C, 50V, 20%, 2.2uF, COMM 856752-2R2M1HAA
