Bose S1 PRO+ Service Manual

19
MAIN-I/O PCB PARTS LIST
Capacitors (continued)
Reference Designator Description Material Number Note
C23, C30, C32, C39, C76,
C82, C88, C90, C92,
C95, C103, C105, C140,
C143, C148, C151, C154,
C157, C242, C356-C357,
C359-C360, C362, C365,
C368, C379
CAP, X5R, 0402, 10V, 20%, 10uF, COMM 716994-106M1A
C248, C255 CAP, C0G, 0402, 50V, 5%, 33pF, COMM 766718-330J1H
C259, C261, C264-C267 CAP, X5R, 0805, 10V, 20%, 47uF, COMM 743447-476M1A
C34, C101, C268-C269 CAP, X5R, 0805, 25V, 10%, 10uF, COMM 743447-106K1E
C3-C4 CAP, EL, SMT, 105C, 50V, 20%, 220uF, COMM 856752-221M1HED
C5, C21, C142, C145,
C160, C162, C369, C374
CAP, X5R, 0402, 6.3V, 20%, 2.2uF, COMM 716994-225M0J
C52, C58-C59, C63-C64,
C69, C178, C181, C193,
C196, C208A, C208B,
C217A, C217B, C224A,
C224B, C228A, C228B
CAP, C0G, 0402, 50V, 5%, 220pF, COMM 766718-221J1H
C53, C68, C168, C171,
C177, C179, C182,
C185-C186, C192, C194,
C198, C371, C396, C212A,
C212B, C223A, C223B
CAP, EL, SMT, 105C, 16V, 20%, 22uF, COMM 856752-220M1CBB
C56, C60-C61, C65,
C169-C170, C173-C174,
C188-C191, C207, C270,
C279, C281, C09A, C209B,
C213A, C213B, C219A,
C219B, C226A, C226B
CAP, C0G, 0402, 50V, 5%, 470pF, COMM 766718-471J1H
C67, C77, C79, C94, C376,
C401, C214A, C214B,
C220A, C220B
CAP, C0G, 0402, 50V, 5%, 47pF, COMM 766718-470J1H
C83, C216A, C216B,
C222A, C222B
CAP, C0G, 0402, 50V, 5%, 1000pF, COMM 766718-102J1H
C9, C12, C14, C18, C20,
C25-C26, C28-C29, C31,
C35-C38, C40, C43-C50,
C54, C78, C80, C85,
C89, C97, C99, C104,
C116, C118, C129-C132,
C147, C153, C175, C183,
C199, C275-C278, C280,
C326-C329, C340-C341,
C165A, C165B, C215A,
C215B, C221A, C221B
CAP, X7R, 0402, 50V, 10%, 10000pF, COMM 718866-103K1H

Bose S1 PRO+ Specifications

General

Type	Handheld Public Address (PA) system
Handle(s)	Yes
Product color	Black
Housing material	Aluminium, Polypropylene (PP)
Storage temperature (T-T)	-20 - 49 °C
Operating temperature (T-T)	0 - 45 °C
Bluetooth range	9 m
Bluetooth version	5.0
Connectivity technology	Wired & Wireless
6.35 mm (1⁄4-inch) input	2
Charging time	5 h
AC input voltage	100 - 240 V
Battery capacity	5500 mAh
Power source type	AC, Battery
AC input frequency	50/60 Hz
Battery life (max)	11 h
Number of mixer channels	3 channels
Speaker type	2-way
Number of speakers	-
Frequency range	- Hz
RMS rated power	- W

Weight and Dimensions

Depth	279.8 mm
Width	240 mm
Height	332.6 mm
Weight	6500 g
