Bose S1 PRO+ Service Manual

20
MAIN-I/O PCB PARTS LIST
Diodes
Inductors
Reference Designator Description Material Number Note
D12 DIODE, SCHOTTKY, 2A, 60V, SOD123F 852398-0010
D14, D17-D18, D21, D27A,
D27B, D49A, D49B
DIODE, SW, 75V, 0.3A, SOT-23, BAV99 747976-0010
D22-D23, D28A, D28B,
D29A, D29B
DIODE, SWITCHING, 100V, 0.15A, SOD323F 856395-0010
D3, D24, D39-D40, D44,
D61-D62
DIODE, TVS, BIDIR, 5V, 13pF, SOD882 863152-0030
D5, D38, D41-D43,
D45-D48, D50-D59
VARISTOR, MULTILAYER, 0402, 130pF, 12V 855757-120M131
D6 DIODE, SCHOTTKY, 30V, BAT54C, SOT-23 330427-0030
D60 DIODE, SCHOTTKY, 30V, BAT54A, SOT-23 330427-0020
D8-D9 DIODE, TVS, BIDIR, 5V, D5V0X1B2LP, 2DFN 859878-0020
LED1 DIODE, LED, 0603, WHITE, VERT 851300-0010
LED10 DIODE, LED, 0606, WHITE, RED, VERT 851297-0010
LED2 DIODE, LED, 0603, BLUE, VERT 851299-0010
LED4-LED6, LED9, LED12,
LED14
DIODE, LED, 0606, RED, BLUE, GREEN,
VERT
851304-0020
Reference Designator Description Material Number Note
L1 INDUCTOR, POWER, SMT, 4.2A, 20%, 10uH,
COMM
852883-100M
L17-L18, L30 INDUCTOR, POWER, SMT, 2.5A, 20%, 22uH,
COMM
853388-220M
L2-L3, L10-L12, L24-L27,
L28A, L28B, L29A, L29B
BEAD, FERRITE, 0402, 0.25A, 1.1 OHM, Z=1K 371767-0010
L4 INDUCTOR, CM, 0805, 0.4A, 25%, 90 OHM,
COMM
879305-900
L5-L9 BEAD, FERRITE, PWR, 0603, 1A, 1000 OHM,
COMM
852198-102

Bose S1 PRO+ Specifications

General

Type	Handheld Public Address (PA) system
Handle(s)	Yes
Product color	Black
Housing material	Aluminium, Polypropylene (PP)
Storage temperature (T-T)	-20 - 49 °C
Operating temperature (T-T)	0 - 45 °C
Bluetooth range	9 m
Bluetooth version	5.0
Connectivity technology	Wired & Wireless
6.35 mm (1⁄4-inch) input	2
Charging time	5 h
AC input voltage	100 - 240 V
Battery capacity	5500 mAh
Power source type	AC, Battery
AC input frequency	50/60 Hz
Battery life (max)	11 h
Number of mixer channels	3 channels
Speaker type	2-way
Number of speakers	-
Frequency range	- Hz
RMS rated power	- W

Weight and Dimensions

Depth	279.8 mm
Width	240 mm
Height	332.6 mm
Weight	6500 g
