Bose S1 PRO+ Service Manual

28
POWER PCB PARTS LIST
Miscellaneous
Reference Designator Description Material Number Note
F1 FUSE, TIME LAG, RADIAL, AMMO PACK,
250V, 5A
871274-5R00A
3
F2-F3 FUSE, SLO-BLO, 1206, 63V, 1.5A 871804-1R50 3
J1 CONN, HDR, 2mm C, 6P, 1R, P, TH, ST, WHT 859609-0006
J2 CONN, FPC, 0.5mm C, 22P, 1R, R, SMT, RA,
Au
857203-0022
J3 CONN.HDR, 2.5mm PITCH, 6P, P, TH, ST,
25.5mmH
871254-0163
J4, J6 CONN, HDR, 1.25mm C, 4P, 1R, P, SMT, ST 845374-0401
J5 CONN, HDR, 2.5mm C, 6P, 1R, R, TH, ST,
WHITE
847750-0006
J7 CONN, HDR, 7.92 mm C, 2P, 1R, P, TH, RA,
WHITE
870484-0002
T3 TRANSFORMER, CUSTOM, 5A, Vout 26Vdc 873604-0010 3
MOV1 VARISTOR, METAL OXIDE, DIA 14mm,
420Vrms
856832-4200D
3

Bose S1 PRO+ Specifications

General

Type	Handheld Public Address (PA) system
Handle(s)	Yes
Product color	Black
Housing material	Aluminium, Polypropylene (PP)
Storage temperature (T-T)	-20 - 49 °C
Operating temperature (T-T)	0 - 45 °C
Bluetooth range	9 m
Bluetooth version	5.0
Connectivity technology	Wired & Wireless
6.35 mm (1⁄4-inch) input	2
Charging time	5 h
AC input voltage	100 - 240 V
Battery capacity	5500 mAh
Power source type	AC, Battery
AC input frequency	50/60 Hz
Battery life (max)	11 h
Number of mixer channels	3 channels
Speaker type	2-way
Number of speakers	-
Frequency range	- Hz
RMS rated power	- W

Weight and Dimensions

Depth	279.8 mm
Width	240 mm
Height	332.6 mm
Weight	6500 g
