Bose S1 PRO+ Service Manual

7
PRODUCT DESCRIPTION
Wireless transmitter charging ports.
Channel inputs (balanced/unbalanced combined or 6.35 mm TS/TRS and XLR).
Signal/clip lights.
Channel controls.
Channel displays.
TRS balanced mono line input ( or 6.35 mm TS/TRS).
AUX stereo line input ( or 3.5 mm TRS).
Bluetooth button.
Bluetooth light.
USB charging port (USB-A).
USB Type-C port.
Line out (XLR). Use an XLR cable to connect a post-mix line-level output to another system.
Power port.
Power light.
Power button.

Bose S1 PRO+ Specifications

General

Type	Handheld Public Address (PA) system
Handle(s)	Yes
Product color	Black
Housing material	Aluminium, Polypropylene (PP)
Storage temperature (T-T)	-20 - 49 °C
Operating temperature (T-T)	0 - 45 °C
Bluetooth range	9 m
Bluetooth version	5.0
Connectivity technology	Wired & Wireless
6.35 mm (1⁄4-inch) input	2
Charging time	5 h
AC input voltage	100 - 240 V
Battery capacity	5500 mAh
Power source type	AC, Battery
AC input frequency	50/60 Hz
Battery life (max)	11 h
Number of mixer channels	3 channels
Speaker type	2-way
Number of speakers	-
Frequency range	- Hz
RMS rated power	- W

Weight and Dimensions

Depth	279.8 mm
Width	240 mm
Height	332.6 mm
Weight	6500 g
