Bose SoundDock 10 Service Manual

16
ELECTRICAL PART LIST
Power PCB Assembly
Reference
Designator
Description Part Number Note
U200 IC, NOR GATE, QUAD, 2-INPUT,
5.5V, SOIC
324043-0010 4
U201 IC, POWER AMP, TDF8599TH,
HSOP36, PAD UP
302183 4
U300 IC, PWR-AMP, Class D, 20W 298092-001 4
U401 IC, Vreg., 5.0V, FIXED., LDO, SOIC 313374-050 4
U501 IC, AMP, OPTICALLY ISOL., 0.5% 310589-001 3,4
U503 IC, VREG, ADJ., 1.2-32V, SOIC 310726-001 4
U504 IC, HALF-BRIDGE GATE DRIVER 317085-001 4
U505 IC, PWM CONTROLLER,
50%DUTY CY
317119-002 4
U506 IC, SCHMITT TRIGGER, 18V,
SSOP-5
317128-001 4
Reference
Designator
Description Part Number Note
F400 FUSE, TIME LAG, 4A, 250V 310538-4000A 4
J400 AC CONN, SINGLE PIECE LEADS 301125-001 3,4
T501 TRANSFORMER,PULSE, RATIO
1:.667
310977-001 3,4
T502 240Uh, XFORMER, OCL, W/QUIET
TAP, 2PIN-UPL
310658-003 3,4
Integrated Circuits
Miscellaneous

Bose SoundDock 10 Specifications

General

Frequency range	- Hz
RMS rated power	- W
Audio output channels	- channels
Bluetooth	Yes
Composite video out	1
Headphone connectivity	-
FM radio	No
Apple docking compatibility	iPhone, iPod
Dimensions (WxDxH)	432 x 244 x 221 mm
Cables included	AC
Product color	Silver

Weight and Dimensions

Weight	8400 g
