Bose SoundDock 10 Service Manual

17
Reference
Designator
Description Part Number Note
Q1200 XSISTOR, BPLR, N, SOT23, 40V,
200mA
146819 4
Q1201 XSISTOR, BPLR, N, SOT23, 40V,
200mA
146819 4
Reference
Designator
Description Part Number Note
C1200 1.0uF, X5R, 0805, 6.3V, 10% 273592-105J 4
C1201 1.0uF, X5R, 0805, 6.3V, 10% 273592-105J 4
C1202 .1uF,X7R, 0603, 50V, 10% 191470-104 4
C1203 .1uF,X7R, 0603, 50V, 10% 191470-104 4
C1204 .1uF,X7R, 0603, 50V, 10% 191470-104 4
Reference
Designator
Description Part Number Note
D1201 DIODE, SWITCHING, 100V, BAV99,
SOT363
319113-001 4
D1202 DIODE, SWITCHING, 100V, BAV99,
SOT363
319113-001 4
D1203 DIODE, SWITCHING, 100V, BAV99,
SOT363
319113-001 4
D1204 DIODE, SOT-23, BAV 99 147239 4
DS1200 DIODE, LED,WHITE, R angle 301111-001 4
DS1201 DIODE, LED,WHITE, R angle 301111-001 4
ELECTRICAL PART LIST
IR PCB Assembly
Reference
Designator
Description Part Number Note
R1200 75 OHM, 0603, .1W, 5% 199403-750 4
R1201 2K, 0603, .1W, 5% 199403-202 4
R1202 47 OHM, 0603, SMD, 100MW, 5% 199403-470 4
R1203 2K, 0603, .1W, 5% 199403-202 4
R1204 75 OHM, 0603, .1W, 5% 199403-750 4
R1205 51 OHM, 0805, 1/10W, 5% 133626-5105 4
R1206 51 OHM, 0805, 1/10W, 5% 133626-5105 4
R1207 51 OHM, 0805, 1/10W, 5% 133626-5105 4
Transistors
Miscellaneous
Reference
Designator
Description Part Number Note
RR1200 IC, IR RECEIVER MODULE 290155-001 4
Capacitors
Integrated Circuits
Resistors
Diodes
Reference
Designator
Description Part Number Note
J1200 CONN, RA, 6-P, 1.0MM PITCH, SMT 319448-006 4

Bose SoundDock 10 Specifications

General

Frequency range	- Hz
RMS rated power	- W
Audio output channels	- channels
Bluetooth	Yes
Composite video out	1
Headphone connectivity	-
FM radio	No
Apple docking compatibility	iPhone, iPod
Dimensions (WxDxH)	432 x 244 x 221 mm
Cables included	AC
Product color	Silver

Weight and Dimensions

Weight	8400 g
