20
Woofer Removal Continued.
7.1 Remove the four Phillips-head screws
holding the woofer in place.
8. End Cap Removal
8.1 Carefully remove the fabric tape on both
sides of the endcap. Remove the three
Phillips-head screws on each side that
secure endcap to the acoustic enclosure.
DISASSEMBLY PROCEDURE CONTINUED
