Bose SoundTouch Portable User Manual

11
ELECTRICAL PART LIST
Resistors (continued)
Reference
Designator
Description Part Number Note
R546 100 OHM, 0402, 63mW, 1% 268361-1000
R547 100 OHM, 0402, 63mW, 1% 268361-1000
R548 100 OHM, 0402, 63mW, 1% 268361-1000
R549 56.2K, 0402, 63mW, 1% 268361-5622
R550 56.2K, 0402, 63mW, 1% 268361-5622
R551 100 OHM, 0402, 63mW, 1% 268361-1000
R552 100 OHM, 0402, 63mW, 1% 268361-1000
R553 56.2K, 0402, 63mW, 1% 268361-5622
R554 56.2K, 0402, 63mW, 1% 268361-5622
R555 1.50K, 0402, 63mW, 1% 268361-1501
R560 56.2K, 0402, 63mW, 1% 268361-5622
R561 56.2K, 0402, 63mW, 1% 268361-5622
R562 100 OHM, 0402, 63mW, 1% 268361-1000
R564 100 OHM, 0402, 63mW, 1% 268361-1000
R565 100 OHM, 0402, 63mW, 1% 268361-1000
R566 100 OHM, 0402, 63mW, 1% 268361-1000
R600 4.53K, 0402, 0.063W, 1% 268361-4531
R601 10.0K, 0402, 63mW, 1% 268361-1002
R602 4.53K, 0402, 0.063W, 1% 268361-4531
R603 340 OHM, 0402, 63mW, 1% 268361-3400
R604 340 OHM, 0402, 63mW, 1% 268361-3400
R606 100 OHM, 0402, 63mW, 1% 268361-1000
R607 10.0K, 0402, 63mW, 1% 268361-1002
R
608 10.0K, 0402, 63mW, 1% 268361-1002
R609 10.0K, 0402, 63mW, 1% 268361-1002
R610 10.0K, 0402, 63mW, 1% 268361-1002
R611 100 OHM, 0402, 63mW, 1% 268361-1000
R612 100 OHM, 0402, 63mW, 1% 268361-1000
R613 100 OHM, 0402, 63mW, 1% 268361-1000
R614 100 OHM, 0402, 63mW, 1% 268361-1000
R615 10.0K, 0402, 63mW, 1% 268361-1002
R616 100 OHM, 0402, 63mW, 1% 268361-1000
R617 100 OHM, 0402, 63mW, 1% 268361-1000
R618 1.00K, 0402, 63mW, 1% 268361-1001
R619 10.0K, 0402, 63mW, 1% 268361-1002
R620 10.0K, 0402, 63mW, 1% 268361-1002
R622 100 OHM, 0402, 63mW, 1% 268361-1000
R657 100 OHM, 0402, 63mW, 1% 268361-1000
R661 3.32K, 0402, 63mW, 1% 268361-3321
R662 3.32K, 0402, 63mW, 1% 268361-3321
R665 10.0K, 0402, 63mW, 1% 268361-1002
R667 10.0K, 0402, 63mW, 1
%
268361-1002
R668 100 OHM, 0402, 63mW, 1% 268361-1000
R669 100 OHM, 0402, 63mW, 1% 268361-1000
R674 100 OHM, 0402, 63mW, 1% 268361-1000
R675 100 OHM, 0402, 63mW, 1% 268361-1000
R676 100 OHM, 0402, 63mW, 1% 268361-1000
R688 100 OHM, 0402, 63mW, 1% 268361-1000
R700 10.0K, 0402, 63mW, 1% 268361-1002
R701 10.0K, 0402, 63mW, 1% 268361-1002
R702 10.0K, 0402, 63mW, 1% 268361-1002
R800 10.0K, 0402, 63mW, 1% 268361-1002
R801 10.0K, 0402, 63mW, 1% 268361-1002
R802 10.0K, 0402, 63mW, 1% 268361-1002
R1000 3.32K, 0402, 63mW, 1% 268361-3321
R1001 3.32K, 0402, 63mW, 1% 268361-3321
R1002 49.9 OHM, 0402, 63mW, 1% 268361-49R9
R1003 56.2K, 0402, 63mW, 1% 268361-5622
R1004 100 OHM, 0402, 63mW, 1% 268361-1000
R100
5
100 OHM, 0402,
6
3mW, 1
%
268361-1000
R1006 100 OHM, 0402, 63mW, 1% 268361-1000
R1007 100 OHM, 0402, 63mW, 1% 268361-1000
R1008 100 OHM, 0402, 63mW, 1% 268361-1000
R1009 100 OHM, 0402, 63mW, 1% 268361-1000
R1010 100 OHM, 0402, 63mW, 1% 268361-1000
R1011 100 OHM, 0402, 63mW, 1% 268361-1000
R1014 100 OHM, 0402, 63mW, 1% 268361-1000
R101
5
100 OHM, 0402, 63mW, 1% 268361-1000
R1016 100 OHM, 0402, 63mW, 1% 268361-1000
R1100 3.32K, 0402, 63mW, 1% 268361-3321
R1101 3.32K, 0402, 63mW, 1% 268361-3321
R1102 100K, 0402, 63mW, 1
%
268361-1003
R1103 100K, 0402, 63mW, 1
%
268361-1003
R1104 1.0M, 0402, 63mW, 1
%
268361-1004
R110
5
1.0M, 0402, 63mW, 1
%
268361-1004
R1106 1.0M, 0402, 63mW, 1
%
268361-1004
R1107 100K, 0402, 63mW, 1
%
268361-1003
Reference
Designator
Description Part Number Note
R1108 100K, 0402, 63mW, 1% 268361-1003
R1111 4.7 OHMS, 0402, 0.063W, 1
%
268361-4R70
R1112 1.0
0
K, 0805, 1/10W, 5
%
13362
6
-1025
R1113 499 OHM, 0805, .125W, 1
%
13362
5
-4990
R1114 4.7 OHMS, 0402, 0.063W, 1% 268361-4R70
R111
5
4.7 OHMS, 0402, 0.063W, 1
%
268361-4R70
R1201 100 OHM, 0402, 63mW, 1
%
268361-1000
R1202 100 OHM, 0402, 63mW, 1
%
268361-1000
R1206 100 OHM, 0402, 63mW, 1% 268361-1000
R1207 100 OHM, 0402, 63mW, 1
%
268361-1000
R1208 100 OHM, 0402, 63mW, 1
%
268361-1000
R1210 100 OHM, 0402, 63mW, 1
%
268361-1000
R1300 10.
0
K, 0402, 63mW, 1
%
268361-1002
R1301 0 OHM, JUMPER, 0402 280043
R1303 100K, 0402, 63mW, 1
%
268361-1003
R1304 100K, 0402, 63mW, 1
%
268361-1003
R1306 215K, 0402, 0.063W, 1% 268361-2153
R1307 100K, 0402, 63mW, 1
%
268361-1003
R1308 24.
0
K, 0402, 63mw, 1% 268361-2402
R1309 10.
0
K, 0402, 63mW, 1
%
268361-1002
R1310 10.0 OHM, 0402, 63mW, 1% 268361-10R0
R1313 100K, 0402, 63mW, 1
%
268361-1003
R1314 100K, 0402, 63mW, 1
%
268361-1003
R131
5
348K, 0402, 63mW, 1
%
268361-3483
R1316 100K, 0402, 63mW, 1
%
268361-1003
R1317 1 OHM, 0402, 0.063W, 1% 268361-1R00
R1318 8.2
5
K, 0402, 0.063W, 1% 268361-8251
R1500 1.5
0
K, 0402, 63mW, 1% 268361-1501
R1501 51 OHMS, 0402, 0.063W, 1% 268361-51R0
R1502 51 OHMS, 0402, 0.063W, 1% 268361-51R0
R1503 1.5
0
K, 0402, 63mW, 1% 268361-1501
R1504 49.9 OHM, 0805, .125W, 1% 13362
5
-49R9
R150
5
51 OHMS, 0402, 0.063W, 1% 268361-51R0
R1506 49.9 OHM, 0805, .125W, 1% 13362
5
-49R9
R1507 274 OHM, 0402, 63mW, 1
%
268361-2740
R1508 274 OHM, 0402, 63mW, 1
%
268361-2740
R1509 75 OHM, 0402, 63mW, 1% 268361-75R0
R1510 75 OHM, 0402, 63mW, 1% 268361-75R0
R1539 100 OHM, 0402, 63mW, 1
%
268361-1000
R1540 100 OHM, 0402, 63mW, 1
%
268361-1000
R1541 100 OHM, 0402, 63mW, 1
%
268361-1000
R1542 100 OHM, 0402, 63mW, 1
%
268361-1000
R1548 100 OHM, 0402, 63mW, 1
%
268361-1000
R1549 100 OHM, 0402, 63mW, 1
%
268361-1000
R1550 100 OHM, 0402, 63mW, 1
%
268361-1000
R1553 12.1K, 0402, 63mW, 1
%
268361-1212
R155
5
100 OHM, 0402, 63mW, 1
%
268361-1000
R1556 4.7
5
K, 0402, 0.063W, 1% 268361-4751
R1557 4.7
5
K, 0402, 0.063W, 1% 268361-4751
R1558 49.9 OHM, 0805, .125W, 1% 13362
5
-49R9
R1559 49.9 OHM, 0805, .125W, 1% 13362
5
-49R9
R1561 4.7
5
K, 0402, 0.063W, 1% 268361-4751
R1562 4.7
5
K, 0402, 0.063W, 1% 268361-4751
R1564 4.7
5
K, 0402, 0.063W, 1% 268361-4751
R1566 4.7
5
K, 0402, 0.063W, 1% 268361-4751
R6100 100 OHM, 0402, 63mW, 1
%
268361-1000
R6102 100 OHM, 0402, 63mW, 1
%
268361-1000
R6103 100 OHM, 0402, 63mW, 1% 268361-1000
R6111 249K, 0402, 0.063W, 1% 268361-2493
Resistors (continued)
SoundTouch™ Wi-Fi Module PCB Assembly

Bose SoundTouch Portable Specifications

General

Connectivity	Wi-Fi, Bluetooth, AUX
Audio formats supported	MP3, WMA, AAC, Apple Lossless
Power	Rechargeable lithium-ion battery
Wireless Range	Up to 30 feet (9 meters)
Audio Input	3.5 mm auxiliary input
Compatibility	SoundTouch app
Voice Control	Amazon Alexa
Water Resistance	No
