Bose SoundTouch Portable - Tera Term Terminal USB Setup; Tera Term Serial Setup

27
TAP COMMAND SET UP (CONTINUED)
1. Tera Term Terminal USB set up
Tera Term is a terminal emulator and can be
downloaded at http://sourceforge.jp/projects/
ttssh2/. It is the interface used to send com-
mands to the SoundTouch™ Portable product.
1.1 Connect the SoundTouch as shown in the
diagram below.
2. Teraterm set up
2.1 Launch a Tera Term terminal window and
select serial communicaton and as shown
below.
Computer
SoundLink
ETAP Adapter
RS 232 to TTL
Converter
Lifestyle
ETAP Cable
SoundTouch
Audio
Out
2.2 Select setup, then serial port to set the
baud rate to 115,200 data to 8 bit, parity to
none, stop to 1 bit and flow conrtol to none.
2.3 Press and hold the AUX button on the
SoundTouch Portable when power is applied
for 12-15 seconds. The product will boot, and
the Tera Term window will display the boot
information.
