13
PHYSICAL SETUP
Tab 6, 14 Tab 8,16Tab 7, 15English Tab 5, 13Tab4, 12Tab 3, 11Tab 2, 10
3. Remove the two stand bolts using a 5/32" (4 mm)
Allen wrench (not included).
4. Attach the monitor cable and AC power cord to the
monitor as shown.
Note: You do not need to re-attach the connector cover.
Hiding the cables behind the monitor may be easier with
the cover removed.
WARNING: The monitor weighs about 110 lbs.
(49.9 kg). To prevent personal injury, a two-person lift
is required.
5. Lift the monitor off the stand.
6. Attach the monitor to the wall according to the
instructions included with the wall bracket.
Note: If using an AC (mains) outlet that is on the wall
behind the monitor, be sure to plug in the power cord
before hanging the monitor.
7. Go to “Control console placement and connec-
tions” on page 14 to continue the physical setup.
