Fuse Replacement
8Fuse replacement of the vehicle power port plug
If the power LED indicator on the power port plug does not illuminate, this indicates the fuse inside the power port
plug is blown. Replace the blown fuse with a new 10A AGC fuse (glass cartridge type).
1. Locate the screw cap on the front end of the power port plug. Turn counterclockwise the screw cap to open
then access the fuse inside.
2. Replace with a new fuse (not included). Then replace the power port plug while ensuring the contact head
sticks out.
1
Screw cap and
contact head
AGC fuse (10A)
9
