16
Using the EXP/CTL Jack
ā
With an expression pedal (the optional
Roland EV-5) connected to the EXP/
CTL jack, the wah and Humanizer ef-
fects are then applied in response to
the operation of the pedal.
* Set the EV-5's minimum volume to the
lowest setting (0). The wah and
Humanizer effects may not play correctly
if this minimum value is not set.
(1) In UP, DOWN, or TEMPO mode:
Provides the pedal wah effect.
* The DECAY, MANUAL, and SENS
knob functions are disabled.
(2) In SHARP mode:
Provides a pedal wah effect, but featuring
special tone characteristics.
* The DECAY, MANUAL, and SENS
knob functions are disabled.
(3) In HUMANIZER mode:
The pedal action shifts between VOWEL
1 and VOWEL 2.
* In Humanizer mode, the DECAY knob
function is disabled.
* If VOWEL 1 and VOWEL 2 have the
same settings, no change is obtained by
moving the pedal.
VOWEL 2 VOWEL 1
