7
Panel Description
9. F.BACK (Feedback) Knob
This adjusts the feedback level. The number
of times the delay sound is repeated increas-
es as the knob is turned to the right.
* This cannot be used in HOLD mode.
* Oscillation may occur when the knob is set at
certain positions.
10.D.TIME (Delay Time) Knob
This adjusts the delay time. Turning the knob
clockwise lengthens the delay time.
* This cannot be used in HOLD mode.
* The delay times that can be set vary according to
the position of the MODE knob.
11. MODE Knob
This switches the delay effect.
●
Ordinary Delay
* The delay time is doubled when the DD-7 is
connected for long delay output. For more infor-
mation, refer to “Long” (p. 17).
MODE Knob
Delay Time
3200 ms 800-3200 ms
200-800 ms
50-200 ms
1-50 ms
800 ms
200 ms
50 ms
