Bostitch BT200 - TOOL SPECIFICATIONS; FASTENER SPECIFICATIONS; AIR FITTING AND PRESSURE

-4-
TOOL SPECIFICATIONS
TOOL AIR FITTING:
This tool uses a free-flow connector plug, 1/4 N.P.T. The inside diameter should be .200” (5mm) or
larger. The fitting must be capable of discharging tool air pressure when disconnected from the air
supply.
OPERATING PRESSURE:
70 to 120 p.s.i.g. (4.8 to 8.3). Select the operating pressure within this range for best fastener
performance.
DO NOT EXCEED THE RECOMMENDED OPERATING PRESSURE.
AIR CONSUMPTION:
The LHF97125 and BT125 require 2.8 cubic feet per minute (.08 cubic meters) the BT200, SX150,
SX150-BHF and SL150 require 3.1 cubic feet per minute (.09 cubic meters) of free air to operate at
the rate of 100 nails per minute, at 80 p.s.i. (5.6 kg/cm
2
). Take the actual rate at which the tool will be
run to determine the amount of air required. For instance, if your fastener usage averages 50 nails per
minute, you need 50% of the tool’s c.f.m. which is required to operate the tool at 100 nails per minute.
MODEL LENGTH HEIGHT WIDTH WEIGHT
BT125 10-1/8” (257,1mm) 8-1/4” (209,6 mm) 2-5/16” (59,7 mm) 1.9 lb (1.0 kg)
BT200 10-1/8” (257,1mm) 9-5/8” (244.0 mm) 2-5/16” (59,7 mm) 2.1 lb (1.0 kg)
SX150 10-1/8” (257,1mm) 9-5/8” (244.0 mm) 2-5/16” (59,7 mm) 2.3 lb (1.0 kg)
SL150 10-1/8” (257,1mm) 9-5/8” (244.0 mm) 2-5/16” (59,7 mm) 2.4 lb (1.1 kg)
SX150-BHF 10-1/8” (257, 1mm) 9-5/8” (244.0 mm) 2-5/16” (59,7 mm) 3.2 lb (1.4 kg)
LHF97125 10-1/8” (257, 1mm) 8-1/4” (209,6 mm) 2-5/16” (59,7 mm) 2.5 lb (1.1 kg)
S97125 10-1/8” (257, 1mm) 8-1/4” (209,6 mm) 2-5/16” (59,7 mm) 2.1 lb (1.0 kg)
USO56 10-1/8” (257, 1mm) 7-5/8” (178,0 mm) 2-5/16” (59,7 mm) 2.2 lb (1.0 kg)
FASTENER SPECIFICATIONS:
TOOL MODEL BRAD/STAPLE SERIES CROWN WIDTH WIRE SIZE FASTENER RANGE
BT125 BT1300 .050X.040(1.27mmX1.04mm) 5/8”-1-1/4”(15mm-32mm)
BT200 BT1300 .050X.040(1.27mmX1.04mm) 5/8”-2” (15mm-38mm)
SL150 SL5035 5/16”(8.0mm) .050X0.035(1.3X0.89mm) 1/2”-1-1/2”(12mm-38mm)
SX150 SX5035 7/32”(5.6mm) .050X0.035(1.3X0.89mm) 1/2”-1-1/2”(12mm-38mm)
SX150-BHF SX5035 7/32”(5.6mm) .050X0.035(1.3X0.89mm) 1/2”-1-1/2”(12mm-38mm)
LHF97125 SB97 3/16”(4.7mm) .028X0.035(0.7X0.89mm) 1/2”-1-3/8”(12mm-35mm)
S97125 SB97 3/16”(4.7mm) .028X0.035(0.7X0.89mm) 1/2”-1-3/8”(12mm-35mm)
USO56 STCR5019 7/16”(11.1mm) .050X0.019(1.3X0.48mm) 1/4”-9/16”(6mm-14mm)
All screws and nuts are metric
