Bostitch BT200 - LOADING THE TOOL; LOADING SL150, SX150, LHF97125; LOADING BT125, BT200

-7-
EYE PROTECTION which conforms to ANSI specifications and provides
protection against flying particles both from the FRONT and SIDE should
ALWAYS be worn by the operator and others in the work area when loading,
operating or servicing this tool. Eye protection is required to guard against
flying fasteners and debris, which could cause severe eye injury.
The employer and/or user must ensure that proper eye protection is worn. Eye
protection equipment must conform to the requirements of the American
National Standards Institute, ANSI SNT-101-2002 and provide both frontal and
side protection. NOTE: Non-side shielded spectacles and face shields alone do not
provide adequate protection.
TO PREVENT ACCIDENTAL INJURIES:
• Never place a hand or any other part of the body in nail discharge area of tool while the air supply is connected.
• Never point the tool at anyone else.
• Never engage in horseplay.
• Never pull the trigger unless nose is directed at the work.
• Always handle the tool with care.
• Do not pull the trigger or depress the trip mechanism while loading the tool.
LOADING THE BT125, BT200, SL150, SX150 & LHF97125
1
2
1. DEPRESS MAGAZINE RELEASE BUTTON.
2. PULL BACK MAGAZINE.
1. OPEN MAGAZINE FULLY.
2. INSERT FASTENERS, POINTS MUST BE
AGAINST BOTTOM OF MAGAZINE.
PUSH MAGAZINE FORWARD.
CONTINUE PUSHING UNTIL LATCH IS ENGAGED.
1
2
1
2
1
1. DEPRESS MAGAZINE RELEASE BUTTO
N
2
. P
U
LL BA
C
K MA
G
AZINE
.
1. OPEN MAGAZINE FULLY
.
2
. TURN TOOL SIDEWAYS
WITH DISCHARGE AREA
POINTED AWAY FROM
YOURSELF AND OTHERS.
3. LOAD STAPLES IN CHANNEL
.
PUSH MAGAZINE FORWARD
.
CONTINUE PUSHING UNTIL LATCH IS ENGAGED
.
LOADING THE SL150, SX150, LHF97125
LOADING THE BT125, BT200
