FIG 1
FIG 3
FIG 5
FIG 2
FIG 4
BT35
A 263 B 200 C 60 D 1.1 E 76.7 F 84.3
G 71.3 H <2.5 I 7 J 4.2 K 0.59 L 1 / 2
M BC602 N BC603 O O-lube P BT Q 1x1.25 l15-35 R 2.1
S 100 T N/A U N/A
BT50
A 263 B 230 C 60 D 1.17 E 76.1 F 84.1
G 71.1 H <2.5 I 7 J 4.9 K 0.62 L 1 / 2
M BC602 N BC603 O O-lube P BT Q 1x1.25 l15-50 R 2.1
S 100 T N/A7 U N/A
