ELECTRICAL GROUNDING INSTRUCTIONS: (continued)
DUTY CYCLE:
To ensure long life of your BOSTITCH air compressor, do not operate on more than a 50% duty cycle. If this
air compressor pumps air more than 50% of one hour, then the compressor’s capability is less than the air
delivery required by the application. Always match the air volume requirements of the attachment or accessory
with the air volume delivery of the compressor.
NOTICE!: BOSTITCH does not recommend the use of extension cords with compressors. The use of an
extension cord can result in the loss of voltage supplied to the compressor which could prevent the compressor
from starting. For optimum performance, plug the compressor directly into an outlet and increase the length of
airline as needed.
If an extension cord must be used, use these guidelines:
Distance Needed . . . . . . . . . . . . . . . . . . . . . Recommended Gauge
Less than 25 ft. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12 Gauge
25 - 50 ft. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10 Gauge
Greater than 50 ft. . . . . . . . . . . . . . . . . . . . . . . . Not Recommended
-6-
CWC200ST SPECIFICATIONS
Motor: 3.0HP Peak
2.2HP Running
115V – 60HZ
Fuse Requirements: 15 Amps minimum
Operating Pressure: 0 – 135 PSI
Safety Valve Setting: 150 PSI
Displacement:
Air Delivery: 5.1 CFM @ 40 PSI
4.0 CFM @ 90 PSI
Maximum Amps at Working Pressure: 14.5 Amps
Tank Size: 4 Gallons
Air Outlet: 1/4" NPT
Pressure Switch Settings: On @ 105 PSI
Off @ 135 PSI
Weight: 60 lbs.
PSI = Pounds Per Square Inch: CFM = Cubic Feet Per Minute
